Are you tired of using slow and outdated servers that are holding you back from achieving your goals? Look no further than the Lanner ECA-6040A, a powerful 2U 19 rackmount AI server that is designed to help you take your business to the next level. With its 5th Gen Intel Xeon processors, this server is capable of handling even the most demanding tasks with ease. Whether you are a business owner, a researcher, or a developer, this server is the perfect solution for anyone who needs a reliable and high-performance server. The Lanner ECA-6040A is designed to solve the problem of slow and inefficient servers, providing a fast and reliable solution for all your needs.
Lanner ECA-6040A, 2U 19 Rackmount AI Server With 5th Gen Intel Xeon Processors
The Lanner ECA-6040A solves the problem of slow and outdated servers by providing a fast and reliable solution for all your needs. This problem matters to users because it can hold them back from achieving their goals and can lead to frustration and lost productivity. The Lanner ECA-6040A provides a clear solution by offering a powerful and efficient server that can handle even the most demanding tasks. With its advanced features and high-performance capabilities, this server is the perfect solution for anyone who needs a reliable and fast server. The 5th Gen Intel Xeon processors provide a significant boost in performance, making it ideal for applications that require high processing power.
Key Features
- 2U 19 rackmount design
- 5th Gen Intel Xeon processors
- DDR5 4800MHz RDIMM memory
- Max capacity of 1024GB
- 16 x 288-pin DIMM sockets
- 1 x GbE RJ45 for management
- 2 x FHFL (PCIe 16, double width, 350W)
- 2 x LP (PCIe 8)
- 1 x OCP3.0 slot
- 6 x smart fans, swappable
- 1600W AC redundant power supply
Specifications
| Platform |
|
| Form Factor |
2U 19” Rackmount |
| Processor Options |
Intel® Xeon® Processor Scalable Family
(Codenamed Sapphire Rapids-SP/Emerald Rapid-SP/ Sapphire Rapids-EE)
|
| CPU Socket |
1 x LGA 4677 |
| Chipset |
Intel® C741 |
| Security Acceleration |
Yes (By CPU SKU) |
| BIOS |
AMI SPI Flash BIOS |
| System Memory |
|
| Technology |
DDR5 4800MHz RDIMM |
| Max. Capacity |
1024GB |
| Socket |
16 x 288-pin DIMM |
| Networking |
|
| Ethernet Ports |
1 x GbE RJ45 For MGMT |
| LOM |
|
| IO Interface |
1 x LOM Port Via BMC Chip |
| OPMA Slot |
Support AST2600 IPMI Module |
| I/O Interface |
|
| Reset Button |
1 x Reset Button (Default SW Reset) |
| LED |
Power/Status |
| Power Button |
Yes |
| Console |
1 x RJ45 |
| USB |
2 x USB 3.0 |
| Display |
Yes, MiniDP Via IAC-AST2600 IPMI Card |
| Storage |
|
| HDD/SSD Support |
4 x 2.5” HDD/SSD Or 4x U.2 |
| Onboard Slots |
1 x M.2 NVMe (PCIe) 2242/2260 M Key1 x M.2 (PCIe) 2280 M Key |
| Expansion |
|
| PCIe |
2 x FHFL (PCIe16, Double Width, 350W)2 x LP (PCIe8) |
| OCP3.0 |
1 x Slot |
| Miscellaneous |
|
| Watchdog |
Yes |
| Internal RTC with Li Battery |
Yes |
| TPM |
Optional |
| Cooling |
|
| Processor |
Passive CPU Heatsink |
| System |
6 x Smart Fans, Swappable |
| Environmental Parameters |
|
| Temperature |
0~40ºC Operating-20~70ºC Non-Operating |
| Humidity (RH) |
5~90% Operating5~95% Non-Operating |
| System Dimensions |
|
| (WxDxH) |
438 x 580.1 x 88 mm |
| Weight |
20 kg |
| Package Dimensions |
|
| (WxDxH) |
600 x 930 x 270 mm |
| Weight |
21 kg |
| Power |
|
| Type / Watts |
1600W AC Redundant |
| Input |
AC 200~240V @50~60 Hz |
| Certification |
|
| Approvals And Compliance |
RoHS, CE/FCC Class A, UL |
| Order Information |
|
| ECA-6040A |
5th Gen Intel® Xeon® Scalable Processors, 1x GbE RJ45, 2x FHFL, 2x LP,1x OCP3.0 |
