Product Code: GTWY-082
MPN #: NCA-1526A
Are you tired of using slow and outdated network appliances that are holding back your business? Do you need a reliable and efficient solution to manage your network traffic? Look no further than the Lanner NCA-1526A Intel Atom C5325, 64GB Desktop Network Appliance. This powerful device is designed to provide fast and secure network connectivity, making it an essential tool for any business or organization. With its advanced features and capabilities, the Lanner NCA-1526A is the perfect solution for anyone looking to upgrade their network infrastructure.
The Lanner NCA-1526A solves the problem of slow and unreliable network connectivity by providing a fast and efficient solution for managing network traffic. This problem matters to users because it can significantly impact their productivity and ability to conduct business. The Lanner NCA-1526A gives a clear solution by providing advanced features such as Intel QuickAssist Technology and a powerful Intel Atom C5325 processor. These features work together to provide fast and secure network connectivity, making it an essential tool for any business or organization.
| Platform | |
| Form Factor | Desktop |
| Processor Options | Intel® Atom® C5325 (Parker Ridge) |
| Core Numbers | 4/8 Cores |
| CPU Socket | Onboard |
| Chipset | SoC |
| Security Acceleration | Intel® QuickAssist Technology |
| BIOS | AMI SPI Flash BIOS |
| System Memory | |
| Technology | DDR4 2933/2400 MHzECC/Non-ECC SODIMM |
| Max. Capacity | 64GB |
| Socket | 2 x 260-pin SODIMM |
| Networking | |
| Ethernet Ports | 4 x GbE RJ45 2 x 10GbE SFP+ 2 x GbE RJ45 (Optional PoE+ Support) |
| I/O Interface | |
| Reset Button | 1 |
| LED | Power/Status/Storage |
| Power Button | 1 |
| Console | 1 x RJ45 |
| USB | 2 x USB 3.0 |
| LCD Module | N/A |
| Display | N/A |
| Power Input | 2 x DC Jack With Lock |
| Storage | |
| HDD/SSD Support | N/A |
| Expansion | |
| PCIe | N/A |
| Mini-PCIe/M.2 | 1 x Mini-PCIe (PCIe/USB2.0) 2 x M.2 3042/3052 B Key (USB3.0) 1 x M.2 2280 B Key (SATA) |
| SIM Card Slot | 2 x Nano SIM for M.2 |
| Miscellaneous | |
| Watchdog | Yes |
| Internal RTC with Li Battery | Yes |
| TPM | SPI TPM 2.0 |
| Cooling | |
| Processor | Passive CPU Heatsink |
| System | 2 x Cooling Fans w/ Smart Fan |
| Environmental Parameters | |
| Temperature | 0~40ºC Operating, -40~70ºC Non-Operating |
| Humidity (RH) | 5~90% Operating, 5~95% Non-Operating |
| System Dimensions | |
| (WxDxH) | 251 x 200 x 44 mm |
| Weight | 1.5 kg |
| Package Dimensions | |
| (WxDxH) | 360 x 310 x 140 mm |
| Weight | 2.75 kg |
| Power | |
| Type / Watts | 90W Power Adapter |
| Input | AC 100~240V @50~60 Hz |
| Certification | |
| Approvals and Compliance | RoHS, CE/FCC Class B (Without PoE+), UL, VCCI, UKCA |
| Order Information | |
| NCA-1526A |
C5325, 8-core, 2x 2933MHz DDR4 SODIMM, Max. 64GB, 4x GbE RJ45, 2x 10GbE SFP+, 2x GbE RJ45, 90W Adapter |
