If you are looking for a reliable and efficient server to manage your business operations, you might be facing a common problem. Many servers on the market are bulky, expensive, and difficult to maintain. This can lead to wasted resources, decreased productivity, and increased costs. The Lanner NCA-5240B 1U 19 Rackmount Server With Intel Core Series 2 Processors is designed to solve this problem by providing a compact, powerful, and easy-to-use server solution. With its advanced features and efficient design, this server can help you streamline your operations, reduce costs, and improve overall performance. By choosing the right server, you can ensure that your business runs smoothly and efficiently, allowing you to focus on what matters most.
Lanner NCA-5240B 1U 19 Rackmount Server With Intel Core Series 2 Processors with Lanner
Are you tired of using bulky and inefficient servers that waste your time and money? Look no further than the Lanner NCA-5240B 1U 19 Rackmount Server With Intel Core Series 2 Processors. This powerful server is designed to provide a reliable and efficient solution for your business needs. With its compact design and advanced features, this server is perfect for small to medium-sized businesses, as well as larger enterprises. The Lanner NCA-5240B is a great choice for anyone looking for a high-performance server that is easy to use and maintain. By choosing Lanner, you can trust that you are getting a high-quality product that will meet your needs and exceed your expectations.
Key Features
- 1U 19 Rackmount design for compact and space-efficient installation
- Intel Core Series 2 Processors for high-performance processing and efficient operation
- DDR5 4400MT/s ECC or non-ECC UDIMM memory for fast and reliable data access
- 4 x 288-pin DIMM sockets for expandable memory and increased capacity
- 1 x PCI-E*4 FH/HL (Optional) for flexible expansion and customization
- 4 x Cooling Fans With Smart Fan for efficient cooling and reduced noise
- 2 x 2.5 SSD/HDD Internal for secure and reliable data storage
- 1 x M.2 2280 (NVMe) for fast and efficient data transfer
- AC 100 to 240V @50 to 60 Hz power input for flexible and reliable power supply
- RoHS, CE / UKCA /FCC Class A, UL certification for guaranteed safety and compliance
Specifications
| Platform |
|
| Form Factor |
1U 19” Rackmount |
| Processor Options |
Intel® Core™ Series 2 Processors |
| CPU Socket |
1 x LGA1700 |
| Chipset |
Intel R680E |
| BIOS |
AMI SPI Flash BIOS |
| System Memory |
|
| Technology |
DDR5 4400MT/s ECC or non-ECC UDIMM |
| Max. Capacity |
192GB |
| Socket |
4 x 288-pin DIMM |
| Networking |
|
| Ethernet Ports |
1x 1Gb RJ45 Intel® i210-AT 4x 1Gb RJ45 & 4x SFP Intel® i350-AM4 |
| Bypass |
2 Pairs (Gen3) |
| NIC Module Slot |
4 |
| LOM |
|
| IO Interface |
1x RJ45 (Optional) Share with ETH0 |
| OPMA Slot |
Yes |
| I/O Interface |
|
| Reset Button |
1 |
| LED |
Power/Status/Storage |
| Power Button |
1 x ATX Power Switch |
| Console |
1 x RJ45 |
| USB |
2 x USB 3.0 |
| LCD Module |
4 x Keypads, 16x2 Character LCD |
| Display |
From OPMA Slot (Optional) |
| Power Input |
AC |
| Storage |
|
| HDD/SSD Support |
2 x 2.5” SSD/HDD Internal |
| Onboard Slots |
1 x M.2 2280 (NVMe) |
| Expansion |
|
| PCIe |
1 x PCI-E*4 FH/HL (Optional) |
| Mini-PCIe/M.2 |
N/A |
| SIM Slot |
N/A |
| Miscellaneous |
|
| Watchdog |
Yes |
| Internal RTC with Li Battery |
Yes |
| TPM |
Optional (TPM 2.0) |
| Cooling |
|
| Processor |
Passive CPU Heatsink |
| System |
4 x Cooling Fans With Smart Fan |
| Environmental Parameters |
|
| Temperature |
0~40ºC Operating |
| Temperature |
-40~70ºC Non-Operating |
| Humidity (RH) |
5~90% Operating |
| Humidity (RH) |
5~95% Non-Operating |
| System Dimensions |
|
| (WxDxH) |
438 x 468 x 44 mm |
| Weight |
7.39 kg |
| Package Dimensions |
|
| (WxDxH) |
739 x 582 x 215 mm |
| Weight |
12.24 kg |
| Power |
|
| Type / Watts |
350W Single PSU |
| Input |
AC 100 to 240V @50 to 60 Hz |
| Certification |
|
| Approvals and Compliance |
RoHS, CE / UKCA /FCC Class A, UL |
| Ordering information |
|
| NCA-5240B |
ntel® Core™ Series 2 Processors (Bartlett Lake-S), 4x GbE w/ Bypass, 4x SFP, 1x Console,
4x NICs, 1x LCM, 1x TPM2.0 (Optional), 1x IPMI (Optional), 1x M.2 2280 NVMe Slot,
350W Single AC PSU, Supports Max. CPU TDP Up To 65W
|
