Meetings just got easier
The ThinkSmart Hub meeting room device is making meetings more efficient than ever. Built on the Microsoft Teams platform, the redesigned Hub has a slimmer design with a sleeker display, more speakers and microphones, an innovative single-cable mechanism, and more visible indicator lights. It’s still scalable across room sizes and features one-touch meeting start, for the best possible Microsoft Teams experience. The built-for-business Intel vPro® platform delivers the performance, security features, manageability, and stability IT needs and users want.
Specifications
| Display |
| Anti-glare screen |
Yes |
| Display brightness |
320 cd/m² |
| Native aspect ratio |
16:10 |
| HD type |
WUXGA |
| Touchscreen |
Yes |
| Display resolution |
1920 x 1200 pixels |
| Display diagonal |
25.6 cm (10.1") |
| Processor |
| Processor cache type |
Smart Cache |
| Processor cache |
6 MB |
| Processor frequency |
1.6 GHz |
| Processor boost frequency |
4.1 GHz |
| Processor cores |
4 |
| Processor model |
i5-8365UE |
| Processor generation |
8th gen Intel® Core™ i5 |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Memory |
| Memory clock speed |
2666 MHz |
| Maximum internal memory |
16 GB |
| Internal memory type |
DDR4-SDRAM |
| Internal memory |
16 GB |
| Storage |
| Card reader integrated |
No |
| Optical drive type |
No |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| SSD interface |
PCI Express 3.0 |
| SSD capacity |
256 GB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
256 GB |
| Storage media |
SSD |
| Total storage capacity |
256 GB |
| Graphics |
| On-board graphics card model |
Intel® HD Graphics |
| On-board graphics card family |
Intel® HD Graphics |
| On-board GPU manufacturer |
Intel |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| Discrete graphics card |
No |
| Audio |
| Built-in microphone |
Yes |
| RMS rated power |
12 W |
| Number of speakers |
4 |
| Built-in speaker(s) |
Yes |
| Camera |
| Built-in camera |
No |
| Network |
| Bluetooth version |
5.0 |
| Bluetooth |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Antenna type |
2x2 |
| WLAN controller model |
Intel Dual Band Wireless-AC 9560 |
| WLAN controller manufacturer |
Intel |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Ports & interfaces |
| Combo headphone/mic port |
Yes |
| DisplayPorts quantity |
1 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Design |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Colour name |
Black |
| Product colour |
Black |
| Performance |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| Motherboard chipset |
Intel SoC |
| Product type |
All-in-One PC |
| Software |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 IoT Enterprise SAC |
| Power |
| AC adapter input voltage |
100 - 240 V |
| AC adapter frequency |
50 - 60 Hz |
| AC adapter power |
90 W |
| Weight & dimensions |
| Weight (with stand) |
2.45 kg |
| Height (with stand) |
185.3 mm |
| Depth (with stand) |
200 mm |
| Width (with stand) |
240 mm |
| Certificates |
| Certification |
TÜV Rheinland Ultra Low Noise |
| Compliance certificates |
RoHS |
| Packaging content |
| Keyboard included |
Yes |
| Mouse included |
Yes |
| Technical details |
| Box contents |
ThinkSmart One Cable (1.83m) |
