Enhance your workspace with the Lenovo ThinkCentre Tiny-In-One 22 21.5" Full HD LED Monitor, featuring a 1920 x 1080 resolution for crisp and vibrant visuals. Its modular design, wide viewing angles, and reliable performance make it ideal for office work, study, and everyday multimedia tasks.
One machine to connect you with the world.
Multitask with multiple devices.
The ThinkCentre Tiny-In-One (TIO) 22 Gen 5 is an all-rounder with its 21.5-inch FHD In-Plane Switching panel which provides an immersive video calling experience. This Modular design of the monitor makes it compatible with Lenovo’s range of high-performance ThinkCentre and ThinkStation Tiny Computers from 4th Gen, and gives a complete working experience when paired with its VoIP features. This can be installed on your monitor effortlessly and housed on the back of the monitor in a dedicated slot, making your desk cable-free. The classic installation mechanism ensures you have a consistent experience, allowing you to easily and quickly mount last-gen Tiny PCs on the monitor. Designed to be a powerful VoIP machine, this monitor is enhanced with features that make video conferencing a great experience. During online meetings, the 1080p RGB webcam and integrated noise-cancellation microphone produce exceptionally clear audio and video. TIO 22 Gen 5 also has a Smart Traffic Light indicator that alerts everyone in the vicinity to an ongoing meeting, letting you remain focused. If remaining focused and staying in the conversation is of importance to you, then the two built-in 3W speakers ensure that the audio from meetings is always clear and crisp. Easily manage VoIP calls with one toggle to change the volume or mute the call using the dedicated VoIP buttons. Your privacy is in your hands with the
ThinkShutter, which allows you to cover the camera when not in its use. Lenovo takes care of the environment with green packaging and optional CO2 offset service for zero to minimal carbon emission. In addition to Tiny PCs, this monitor can also be easily connected to other notebooks, towers using the HDMI and DP ports, and to other peripherals using the USB ports. With the ThinkColour software1, customize the screen’s attributes, create screen profiles, and easily switch between them as per your work preference. Protects your eyes from harmful blue light without any color distortion during long
hours of screen time with the Natural Low Blue Light technology. The TIO 22 Gen 5 is the perfect option if you’re looking for a clean and clutter-free setup to maximize productivity and enjoy an efficient, all-in-one experience.
Specifications
| Display |
| sRGB coverage (typical) |
99% |
| Colour gamut |
99% |
| Colour gamut standard |
sRGB |
| Colour depth |
8 bit |
| Viewable size, vertical |
26.8 cm |
| Viewable size, horizontal |
47.6 cm |
| Pixel density |
102 ppi |
| Pixel pitch |
0.248 x 0.248 mm |
| Response time (fast) |
4 ms |
| Display number of colours |
16.7 million colours |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Maximum refresh rate |
60 Hz |
| Contrast ratio (dynamic) |
3000000:1 |
| Contrast ratio (typical) |
1000:1 |
| Screen shape |
Flat |
| Anti-glare screen |
Yes |
| Response time |
6 ms |
| Display brightness (typical) |
250 cd/m² |
| Backlight type |
W-LED |
| Panel type |
IPS |
| HD type |
Full HD |
| Touchscreen |
No |
| Display technology |
LED |
| Native aspect ratio |
16:9 |
| Display resolution |
1920 x 1080 pixels |
| Display diagonal |
54.6 cm (21.5") |
| Performance |
| Low Blue Light technology |
Yes |
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Multimedia |
| Built-in microphone |
Yes |
| Built-in camera |
Yes |
| RMS rated power |
6 W |
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| Design |
| Product colour |
Black |
| Ports & interfaces |
| DisplayPort version |
1.2 |
| DisplayPorts quantity |
1 |
| HDMI version |
1.4 |
| HDMI ports quantity |
1 |
| HDMI |
Yes |
| USB Type-A downstream ports quantity |
1 |
| Number of USB Type-B upstream ports quantity |
1 |
| Number of upstream ports |
1 |
| USB upstream port type |
USB Type-B |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| Built-in USB hub |
Yes |
| Ergonomics |
| On Screen Display (OSD) |
Yes |
| Tilt angle range |
-5 - 23.5° |
| Swivel angle range |
-45 - 45° |
| Swivelling |
Yes |
| Pivot angle |
-5 - 90° |
| Pivot |
Yes |
| Adjustable height (max) |
15.5 cm |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Cable management |
Yes |
| Panel mounting interface |
100 x 100 mm |
| VESA mounting |
Yes |
| Power |
| Power supply type |
External |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power consumption (off) |
0.5 W |
| Power consumption (max) |
33 W |
| Power consumption (standby) |
0.3 W |
| Power consumption (typical) |
13.4 W |
| Weight & dimensions |
| Bezel width (bottom) |
4.6 cm |
| Bezel width (top) |
2 mm |
| Bezel width (side) |
2 mm |
| Weight (without stand) |
3.2 kg |
| Height (without stand) |
339.1 mm |
| Depth (without stand) |
72.8 mm |
| Width (without stand) |
489.3 mm |
| Weight (with stand) |
5.5 kg |
| Height (with stand) |
512.3 mm |
| Depth (with stand) |
207.6 mm |
| Width (with stand) |
489.3 mm |
| Packaging data |
| Package weight |
8.1 kg |
| Package height |
422 mm |
| Package depth |
176 mm |
| Package width |
568 mm |
| Packaging content |
| Power cable length |
1 m |
| Quick start guide |
Yes |
| Power adapter included |
Yes |
| Cables included |
AC |
| Stand included |
Yes |
| Other features |
| Certification |
EU Energy Label (D-class) ENERGY STAR® Certified EPEAT™ Gold Registered TCO Certified 9.0 TCO edge 2.0 Volatile Organic Compound Certification RoHS compliant Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Eye Comfort |
| Package weight |
8.1 kg |
| Warranty period |
3 year(s) |
| Compatible operating systems |
Windows 10, Windows 11 |
