| Processor |
| Number of processors installed |
1 |
| Configurable TDP-down |
12 W |
| Configurable TDP-down frequency |
1.1 GHz |
| Configurable TDP-up |
28 W |
| Configurable TDP-up frequency |
2.6 GHz |
| Processor cache |
8 MB |
| Processor frequency |
1.5 GHz |
| Processor boost frequency |
4.1 GHz |
| Processor threads |
8 |
| Processor cores |
4 |
| Processor model |
i5-1145GRE |
| Processor generation |
11th gen Intel® Core™ i5 |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Memory |
| Memory clock speed |
3200 MHz |
| Internal memory type |
DDR4-SDRAM |
| Maximum internal memory |
16 GB |
| Internal memory |
16 GB |
| Storage |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| SSD interface |
NVMe, PCI Express 3.0 |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
512 GB |
| Storage media |
SSD |
| Optical drive type |
No |
| Total storage capacity |
512 GB |
| Graphics |
| On-board graphics card model |
Intel Iris Xe Graphics |
| On-board GPU manufacturer |
Intel |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| Network |
| Wake-on-LAN ready |
Yes |
| Bluetooth version |
5.1 |
| Bluetooth |
Yes |
| Antenna type |
2x2 |
| WLAN controller model |
Intel Dual Band Wireless-AC 9560 |
| WLAN controller manufacturer |
Intel |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
100,1000,2500 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| Serial ports quantity |
2 |
| DC-in jack |
Yes |
| Combo headphone/mic port |
Yes |
| Ethernet LAN (RJ-45) ports |
2 |
| DisplayPort version |
1.4a |
| DisplayPorts quantity |
1 |
| HDMI ports quantity |
0 |
| Thunderbolt 4 ports quantity |
1 |
| Intel® Thunderbolt 4 |
Yes |
| Thunderbolt 3 ports quantity |
0 |
| USB4 Gen 3x2 ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 2.0 ports quantity |
0 |
| Design |
| Intel® vPro™ Platform Eligibility |
Yes |
| Viewing window |
No |
| Product colour |
Black |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Volume |
0.81 L |
| Colour name |
Black |
| Chassis type |
Mini PC |
| Performance |
| Trusted Platform Module (TPM) |
Yes |
| Motherboard chipset |
Intel SoC |
| Product type |
Mini PC |
| Software |
| Operating system installed |
Windows 10 IoT Enterprise |
| Processor special features |
| CPU configuration (max) |
1 |
| Embedded options available |
Yes |
| Idle States |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
No |
| Intel Trusted Execution Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Power |
| Power supply |
65 W |
| Operational conditions |
| Operating shock |
30 G |
| Operating vibration |
3 G |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating temperature (T-T) |
-20 - 60 °C |
| Certificates |
| Certification |
ErP Lot 6, Low Halogen, PCF |
| Compliance certificates |
RoHS, WEEE |
| Weight & dimensions |
| Weight |
1.02 kg |
| Height |
51.5 mm |
| Depth |
88 mm |
| Width |
179 mm |
| Packaging content |
| Keyboard included |
Yes |
| Mouse included |
Yes |
| Display |
| Display included |
No |
| Other features |
| Maximum internal memory |
16 GB |
| Operating temperature (T-T) |
-20 - 60 °C |
