Ever tried to render a complex 3D model and your PC stalls after a few minutes? You need a Lenovo workstation that can keep up with massive simulations without freezing. The Lenovo ThinkStation P620 delivers raw compute power and reliable memory, so your projects finish on schedule.
Lenovo ThinkStation P620, 3.8 GHz, 5965WX, 64GB/1TB W11 Pro Tower PC
The ThinkStation P620 is a tower workstation built for professionals who run CAD, simulation, or data-analysis software. It packs a 24-core AMD Ryzen Threadripper PRO processor, 64 GB ECC DDR4 memory, and a 1 TB NVMe SSD, providing the bandwidth and stability required for large files.
Benefits
- Render complex scenes in minutes, not hours.
- Edit multi-gigabyte datasets without crashes.
- Add or upgrade graphics cards for future projects.
- Secure your work with built-in TPM and password protection.
- Connect to fast 10 GbE networks for quick file transfers.
- Keep the system cool during long simulations with advanced airflow.
Features
- AMD Ryzen Threadripper PRO 5965WX 24-core CPU
- 64 GB DDR4 ECC memory, octa-channel
- 1 TB NVMe PCIe 4.0 SSD storage
- Four PCIe 4.0 x16 slots for expansion
- Dual USB-C 3.2 Gen 2 ports
- Six USB-A 3.2 Gen 2 ports, two USB-2.0
- 1000 W power supply, reliable delivery
- Lenovo certified ISV support and manageability
Specifications
| Processor |
| Number of processors installed |
1 |
| Processor cache type |
L3 |
| Processor cache |
128 MB |
| Processor frequency |
3.8 GHz |
| Processor boost frequency |
4.5 GHz |
| Processor threads |
48 |
| Processor cores |
24 |
| Processor model |
5965WX |
| Processor generation |
AMD Ryzen Threadripper PRO 5000 WX-Series |
| Processor family |
AMD Ryzen Threadripper PRO |
| Processor manufacturer |
AMD |
| Memory |
| ECC |
Yes |
| Memory channels |
Octa-channel |
| Memory clock speed |
3200 MHz |
| Memory slots |
8x DIMM |
| Memory layout (slots x size) |
4 x 16 GB |
| Internal memory type |
DDR4-SDRAM |
| Maximum internal memory |
1.02 TB |
| Internal memory |
64 GB |
| Storage |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| SSD interface |
NVMe, PCI Express 4.0 |
| SSD capacity |
1 TB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
1 TB |
| Storage media |
SSD |
| Optical drive type |
No |
| Total storage capacity |
1 TB |
| Graphics |
| On-board graphics card model |
Not available |
| Discrete graphics card model |
Not available |
| On-board graphics card |
No |
| Discrete graphics card |
No |
| Network |
| Bluetooth |
No |
| Wi-Fi |
No |
| LAN controller |
Marvell AQtion AQN-107 |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
100,1000,2500,10000 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| Combo headphone/mic port |
Yes |
| Line-in |
Yes |
| Line-out |
Yes |
| Headphone outputs |
1 |
| Microphone in |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| PS/2 ports quantity |
2 |
| HDMI ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
6 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 2.0 ports quantity |
2 |
| Expansion slots |
| PCI Express x16 (Gen 4.x) slots |
4 |
| PCI Express x8 (Gen 4.x) slots |
2 |
| Design |
| Product colour |
Black |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Number of 5.25" bays |
1 |
| Number of 3.5" bays |
2 |
| Placement supported |
Vertical |
| Volume |
33 L |
| Colour name |
Black |
| Chassis type |
Tower |
| Performance |
| Trusted Platform Module (TPM) |
Yes |
| Password protection type |
Power on, Supervisor |
| Password protection |
Yes |
| Audio system |
High Definition Audio |
| Audio chip |
Realtek ALC4050H |
| Motherboard chipset |
AMD WRX80 |
| Product type |
Workstation |
| Software |
| Operating system language |
English |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Power |
| Power supply |
1000 W |
| Operational conditions |
| Non-operating altitude |
0 - 12192 m |
| Operating altitude |
0 - 3048 m |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating temperature (T-T) |
10 - 35 °C |
| Certificates |
| Certification |
EPEAT Silver ENERGY STAR 8.0 (on model 30E00006US) GREENGUARD RoHS compliant |
| Compliance certificates |
RoHS |
| Sustainability |
| Sustainability certificates |
ENERGY STAR, EPEAT Silver, GREENGUARD |
| Weight & dimensions |
| Weight |
24 kg |
| Height |
446 mm |
| Depth |
455 mm |
| Width |
165 mm |
| Packaging content |
| Keyboard included |
Yes |
| Mouse included |
Yes |
| Other features |
| Maximum internal memory |
1.02 TB |
| Operating temperature (T-T) |
10 - 35 °C |
