| Management features |
| ARP inspection |
Yes |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2 |
| Switch type |
Managed |
| Ports & interfaces |
| Console port |
RJ-45 |
| Installed SFP+ modules quantity |
0 |
| Installed SFP modules quantity |
2 |
| Gigabit Ethernet (copper) ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Network |
| Virtual LAN features |
MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| VLAN support |
Yes |
| Auto-negotiation |
Yes |
| Broadcast storm control |
Yes |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| Spanning tree protocol |
Yes |
| Port mirroring |
Yes |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| 10G support |
No |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Data transmission |
| Jumbo frames |
10000 |
| Jumbo frames support |
Yes |
| Static route |
Yes |
| MAC address table |
8000 entries |
| Security |
| BPDU filtering/protection |
Yes |
| MAC address filtering |
Yes |
| Password protection |
Yes |
| DHCP features |
DHCP Option 82, DHCP client, DHCP relay, DHCP snooping |
| Multicast features |
| Multicast support |
Yes |
| Design |
| DIN rail mounting |
Yes |
| LED indicators |
Activity, Link, PoE, Power |
| Product colour |
Black |
| Rack mounting |
No |
| Performance |
| Mean time between failures (MTBF) |
338634 h |
| Fanless |
Yes |
| Noise level |
0 dB |
| Flash memory |
128 MB |
| Internal memory |
1024 MB |
| Power |
| Power consumption (max) |
380 W |
| Power consumption (typical) |
5 W |
| DC input voltage |
48 - 57 V |
| Power source |
DC |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
360 W |
| Power over Ethernet (PoE) power per port |
10 W |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
-40 - 75 °C |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating temperature (T-T) |
-40 - 75 °C |
| Weight & dimensions |
| Weight |
500 g |
| Height |
50 mm |
| Depth |
115 mm |
| Width |
165 mm |
| Packaging content |
| Quick start guide |
Yes |
| Packaging data |
| Package weight |
1.13 kg |
| Package height |
74 mm |
| Package depth |
181 mm |
| Package width |
270 mm |
| Package type |
Box |
| Certificates |
| Certification |
CE, RoHS |
