| CPU Socket |
AMD Socket AM5 |
| Supported Processors |
AMD Ryzen 9000/8000/7000 Series |
| Memory Type |
DDR5 DIMM |
| Memory Slots |
4 × DDR5 DIMM |
| Maximum Memory |
Up to 256GB (4 × 64GB) |
| Memory Architecture |
Dual Channel |
| Supported Memory Speeds |
DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s |
| Memory Compatibility |
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| Memory Profiles |
Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules |
| Integrated Graphics |
Integrated Graphics Processor with AMD Radeon™ Graphics support
• 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
• Support for HDMI 2.1 version and HDCP 2.3, and HDR.
• Support for native HDMI 2.1 TMDS compatible ports.
• 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz
• Support for DisplayPort 1.4 version.
(Graphics specifications depending on CPU support.)
Support for up to triple-display at the same time
|
| Audio |
Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel |
| LAN |
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
|
|
Wireless Communication module
|
Realtek® Wi-Fi 6E RTL8852CE
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.3
- Support for 11ax 160MHz wireless standard |
| Expansion Slots |
1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
• AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode
• AMD Ryzen™ 8000 Series, Phoenix 1 Processors support PCIe 4.0 x8 mode
• AMD Ryzen™ 8000 Series, Phoenix 2 Processors support PCIe 4.0 x4 mode
Chipset:
• 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIeX4)
|
| Storage Interface |
1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
• AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
• AMD Ryzen™ 8000 Series, Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
• AMD Ryzen™ 8000 Series, Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
• AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs
• AMD Ryzen™ 8000 Series, Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
• AMD Ryzen™ 8000 Series, Phoenix 2 Processors support PCIe 4.0 x2 SSDs
4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
* RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
RAID 0, RAID 1, and RAID 10 support for SATA storage devices
|
| USB |
CPU:
• 1 x USB Type C® port on the back panel, with USB 3.2 Gen 2 support
• 1 x USB 3.2 Gen 2 Type A port (red) on the back panel
CPU + USB 2.0 Hub:
• 4 x USB 2.0/1.1 ports on the back panelChipset:
• 1 x USB Type C® port with USB 3.2 Gen 2 support, available through the internal USB header
• 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
• 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Internal I/O Connectors |
• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x CPU fan header
• 1 x CPU fan/water cooling pump header
• 1 x system fan header
• 1 x system fan/water cooling pump header
• 3 x addressable RGB Gen2 LED strip headers
• 1 x RGB LED strip header
• 4 x SATA 6Gb/s connectors
• 2 x M.2 Socket 3 connectors
• 1 x front panel header
• 1 x front panel audio header
• 1 x USB Type-C® header, with USB 3.2 Gen 2 support
• 1 x USB 3.2 Gen 1 header
• 2 x USB 2.0/1.1 headers
• 1 x Trusted Platform Module header
• 1 x reset button
• 1 x reset jumper
• 1 x Clear CMOS jumper |
| Back Panel Connectors |
1 x HDMI port2 x DisplayPorts
1 x Q Flash Plus button1 x PS/2 keyboard/mouse port
1 x USB 3.2 Gen 2 Type A port (red)
1 x USB Type C® port with USB 3.2 Gen 2 support
2 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports
1 x RJ 45 port2 x Antenna connectors (2T2R)
3 x Audio jacks
(Note) Actual support may vary by CPU
|
| I/O Controller |
iTE® I/O Controller Chip |
| Hardware Monitoring |
Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control |
| BIOS |
1 x 256 Mbit flash
Licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q Flash
Support for Q Flash Plus
Support for Smart Backup
|
| Bundled Software |
Norton® Internet Security (OEM version)
LAN bandwidth management software |
| Supported Operating System |
Windows 11 64 bit
Windows 10 64 bit |
| Form Factor |
Micro ATX Form Factor |
| Dimensions |
24.4 × 24.4 cm |
