Mitutoyo 174-185A Linear Counter, Linear Scale 3 Axis KA-213 Counter

If you need exact measurements on a moving part, a single bad read can ruin an entire batch. The Mitutoyo 174-185A Linear Counter, Linear Scale 3 Axis KA-213 Counter gives you reliable numbers every time. It reads linear scales on three axes and shows the data on a clear LED display. This tool solves the common problem of inconsistent feed-speed data in machining and helps you keep tight tolerances.

Mitutoyo 174-185A Linear Counter, Linear Scale 3 Axis KA-213 Counter

Many workshops struggle with scale errors that lead to scrap parts and extra set-up time. When the scale input is not read correctly, the machine can cut too deep or miss a feature entirely. This counter connects to AT100 or AT715 scales, offers resolutions down to 0.0001 mm, and displays the result on an 8-digit LED screen. The built-in macro functions for rectangular drilling and round milling let you program common operations without leaving the machine.

Key Features

• Resolution 0.05 mm to 0.0001 mm with AT100 series.
• Resolution 0.01 mm to 0.0005 mm with AT715 series.
• Two or three scale input ports for flexible wiring.
• 7-segment, 8-digit LED display plus sign and 8-character alphabet.
• Feed speed display helps monitor machining velocity.
• Taper machining function supports angled cuts.
• Tool data storage for quick changeover.
• Multi-point compensation improves accuracy over long runs.
• Scale check function verifies scale health before use.
• Built-in calculation function reduces manual math.
• Compact size 30 168 70 mm fits most machine tables.
• Optional RS-232C/USB output for data export.
