| Processor |
| ECC supported by processor |
Yes |
| Thermal Design Power (TDP) |
65 W |
| L3 cache |
20 MB |
| L2 cache |
9.5 MB |
| Processor cache |
20 MB |
| Processor lithography |
10 nm |
| Efficient-core base frequency |
1.8 GHz |
| Performance-core base frequency |
2.5 GHz |
| Efficient-core Max Turbo Frequency |
3.5 GHz |
| Performance-core Max Turbo Frequency |
4.7 GHz |
| Low Power Efficient-cores |
0 |
| Efficient cores |
4 |
| Performance cores |
6 |
| Processor frequency |
2.5 GHz |
| Processor boost frequency |
4.7 GHz |
| Processor threads |
16 |
| Processor cores |
10 |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Built-in processor |
Yes |
| Memory |
| Non-ECC |
Yes |
| ECC |
No |
| Maximum internal memory |
64 GB |
| Memory channels |
Dual-channel |
| Supported memory clock speeds |
5600 MHz |
| Number of memory slots |
0 |
| Storage |
| Card reader integrated |
No |
| Graphics |
| Number of displays supported |
3 |
| Maximum resolution |
4096 x 2160 pixels |
| On-board graphics card model |
Intel UHD Graphics 770 |
| Graphics card family |
Intel |
| On-board graphics card |
Yes |
| Display |
| Touchscreen |
No |
| Audio |
| Built-in speaker(s) |
No |
| Network |
| Bluetooth |
Yes |
| Bluetooth Low Energy (BLE) |
Yes |
| Bluetooth version |
5.3 |
| LAN controller |
Realtek RTL8111H |
| Near Field Communication (NFC) |
No |
| Copper ethernet cabling technology |
10BASE-TX, 100BASE-TX, 1000BASE-TX |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi |
Yes |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| DC-in jack |
No |
| COM ports quantity |
0 |
| CardBus PCMCIA slots quantity |
0 |
| Consumer infrared headers |
No |
| Ethernet LAN (RJ-45) ports |
1 |
| Firewire (IEEE 1394) ports |
0 |
| PS/2 ports quantity |
0 |
| Parallel ports quantity |
0 |
| S/PDIF out port |
No |
| Serial port via internal header |
No |
| Serial ports quantity |
0 |
| TV-out |
No |
| Thunderbolt 3 ports quantity |
0 |
| Thunderbolt 4 ports quantity |
0 |
| Thunderbolt ports quantity |
0 |
| USB charging |
Yes |
| eSATA ports quantity |
0 |
| Combo headphone/mic port |
No |
| Headphone outputs |
1 |
| Microphone in |
Yes |
| DisplayPort version |
1.4 |
| Mini DisplayPorts quantity |
0 |
| DisplayPorts quantity |
1 |
| DVI-D ports quantity |
0 |
| DVI port |
No |
| VGA (D-Sub) ports quantity |
0 |
| HDMI version |
2.1 |
| Mini HDMI ports quantity |
0 |
| HDMI ports quantity |
1 |
| USB4 Gen 3x2 ports quantity |
0 |
| USB4 Gen 2x2 ports quantity |
0 |
| Internal USB 3.2 Gen 1 (3.1 Gen 1) ports quantity |
2 |
| Internal USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 2.0 ports quantity |
4 |
| Expansion slots |
| Number of M.2 (M) slots |
2 |
| PCI-X slots |
0 |
| Mini PCI Express slot (full length) |
0 |
| Mini PCI Express slot (half-length) |
0 |
| Mini PCI Express slots |
0 |
| PCI slots |
0 |
| PCI Express x16 (Gen 5.x) slots |
0 |
| PCI Express x16 slots |
1 |
| PCI Express x8 slots |
0 |
| PCI Express x4 (Gen 2.x) slots |
0 |
| PCI Express x4 slots |
0 |
| PCI Express x1 slots |
1 |
| PCI Express slots version |
4.0 |
| Design |
| Product type |
Mini PC barebone |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Housing material |
Metal, Plastic |
| LED indicators |
Yes |
| On/off switch |
Yes |
| Cooling type |
Active |
| Product colour |
Black |
| Chassis type |
Mini-Tower |
| Performance |
| Consumer infrared Rx sensor |
No |
| Audio chip |
Realtek ALC897 |
| Audio output channels |
7.1 channels |
| Trusted Platform Module (TPM) version |
2.0 |
| Trusted Platform Module (TPM) |
Yes |
| ACPI version |
6.3 |
| BIOS memory size |
256 Mbit |
| BIOS type |
UEFI |
| Supported processor frequency (max) |
4.7 GHz |
| Compatible processor series |
Intel Core i5 14th Gen |
| Number of processors supported |
1 |
| Processor socket |
LGA 1700 |
| Motherboard chipset |
Intel H610 |
| Motherboard form factor |
micro ATX |
| Processor special features |
| Conflict-Free |
Yes |
| Embedded options available |
No |
| Enhanced Intel SpeedStep Technology |
Yes |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Intel 64 |
Yes |
| Intel Advanced Management Technology |
No |
| Intel Clear Video Technology |
Yes |
| Intel Demand Based Switching |
No |
| Intel Dual Display Capable Technology |
Yes |
| Intel Express BIOS update |
No |
| Intel FDI Technology |
No |
| Intel Fast Memory Access |
No |
| Intel Flex Memory Access |
Yes |
| Intel On-Demand Power Redundancy Technology |
No |
| Intel Rapid Storage Technology |
Yes |
| Intel Smart Connect Technology |
No |
| Intel Stable Image Platform Program (SIPP) |
No |
| Intel TSX-NI |
No |
| Intel Trusted Execution Technology |
No |
| Intel Unite installed |
No |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Visual BIOS |
No |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Anti-Theft Technology (Intel® AT) |
No |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel® High Definition Audio (Intel® HD Audio) |
Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Intel® InTru™ 3D Technology |
No |
| Intel® Insider™ |
No |
| Intel® Matrix Storage Technology (Intel® MST) |
No |
| Intel® My WiFi Technology (Intel® MWT) |
No |
| Intel® OS Guard |
Yes |
| Intel® Optane™ Memory Ready |
Yes |
| Intel® Platform Trust Technology (Intel® PTT) |
Yes |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® Rapid Start Technology |
No |
| Intel® Secure Key |
Yes |
| Intel® Small Business Advantage (Intel® SBA) |
No |
| Intel® Smart Cache |
Yes |
| Intel® Smart Response Technology |
No |
| Intel® Turbo Boost Technology |
Yes |
| Intel® Unite™ |
No |
| Intel® Virtualization Technology (Intel® VT) |
Yes |
| Intel® Wireless Display (Intel® WiDi) |
No |
| Thermal Monitoring Technologies |
Yes |
| Intel® vPro™ Platform Eligibility |
No |
| Certificates |
| Waste Electrical and Electronic Equipment (WEEE) compliance |
Yes |
| Software |
| Windows operating systems supported |
No |
| Technical details |
| Compliance certificates |
BSMI, CB, CE, Federal Communications Commission (FCC) |
| Power |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Number of power supply units |
1 |
| Power supply |
120 W |
| Power supply type |
External AC adapter |
| Operational conditions |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Weight & dimensions |
| Package weight |
2.8 kg |
| Package height |
122 mm |
| Package depth |
382 mm |
| Package width |
271 mm |
| Weight |
1.27 kg |
| Height |
54.8 mm |
| Depth |
280 mm |
| Width |
204 mm |
| Packaging content |
| Keyboard included |
No |
| Mouse included |
No |
| Display included |
No |
| Drivers included |
Yes |
| Quick start guide |
Yes |
| AC adapter included |
Yes |
| Power cord included |
Yes |
| Other features |
| Country of origin |
China |
| Introduction month |
June |
| Introduction year |
2025 |
| Warranty period |
3 year(s) |
