| Management features |
| ARP inspection |
Yes |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L3 |
| Switch type |
Managed |
| Ports & interfaces |
| Power connector |
AC-in jack |
| SFP+ module slots quantity |
4 |
| Installed SFP+ modules quantity |
0 |
| Installed SFP modules quantity |
0 |
| Gigabit Ethernet (copper) ports quantity |
48 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Network |
| Number of VLANs |
4093 |
| Virtual LAN features |
MAC address-based VLAN, Private VLAN, Voice VLAN |
| VLAN support |
Yes |
| 6to4 tunnel |
Yes |
| Broadcast storm control |
Yes |
| Flow control support |
Yes |
| IPv4 routes |
512 |
| IPv6 routes |
256 |
| Link aggregation |
Yes |
| Rate limiting |
Yes |
| Spanning tree protocol |
Yes |
| Full duplex |
Yes |
| Policy-based routing |
Yes |
| 10G support |
Yes |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u |
| Data transmission |
| Packet buffer memory |
32 MB |
| Jumbo frames |
12000 |
| Jumbo frames support |
Yes |
| Latency (10 Gbps) |
0.7 µs |
| Latency (1 Gbps) |
2.2 µs |
| Store-and-forward |
Yes |
| Throughput |
130.94 Mpps |
| Throughput |
130.94 Mpps |
| Switching capacity |
176 Gbit/s |
| MAC address table |
16000 entries |
| Security |
| Authentication |
Guest VLAN, MAC-based authentication |
| Authentication type |
RADIUS, TACACS+ |
| BPDU filtering/protection |
Yes |
| DoS attack prevention |
Yes |
| Loop protection |
Yes |
| MAC address filtering |
Yes |
| Password protection |
Yes |
| Queue scheduling algorithms |
Strict Priority Queue (SPQ), Weighted random early detection (WRED) |
| Root protection |
Yes |
| Static port security |
Yes |
| IGMP proxy |
Yes |
| IGMP snooping |
Yes |
| Access Control List (ACL) ingress |
511 |
| Access Control List (ACL) egress |
1023 |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping |
| Multicast features |
| Multicast Listener Discovery (MLD) snooping |
Y |
| Multicast support |
Yes |
| Protocols |
| GARP VLAN Registration Protocol (GVRP) |
Yes |
| Routing protocols |
OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2 |
| Management protocols |
SNMP V1, V2, V3 |
| Design |
| Airflow direction |
Front-to-back airflow |
| LED indicators |
Yes |
| Product colour |
Black |
| Form factor |
1U |
| Stackable |
Yes |
| Rack mounting |
Yes |
| Performance |
| sFlow |
Yes |
| Flash memory |
512 MB |
| Internal memory |
2048 MB |
| Memory type |
DDR4-SDRAM |
| Processor frequency |
1800 MHz |
| Processor model |
ARM Cortex-A57 |
| Built-in processor |
Yes |
| Power |
| Power consumption (max) |
348 W |
| Power consumption (typical) |
99 W |
| Power supply included |
Yes |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
1440 W |
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet plus (PoE+) ports quantity |
48 |
| Power over Ethernet (PoE) |
Yes |
| Other features |
| Power supply |
550 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Non-operating altitude |
0 - 3000 m |
| Operating altitude |
0 - 3000 m |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
0 - 45 °C |
| Weight & dimensions |
| Weight |
7.19 kg |
| Height |
43.2 mm |
| Depth |
400 mm |
| Width |
440 mm |
| Packaging content |
| Rack mount kit |
Yes |
| Quick start guide |
Yes |
| Cables included |
AC, USB Type-C |
| Packaging data |
| Included power plug types |
EU, UK, NA |
| Sustainability |
| Sustainability compliance |
Yes |
| Sustainability certificates |
BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD) |
| Certificates |
| Compliance certificates |
BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD) |
