Imagine a fast, reliable way to test your next automotive control project without building a custom board from scratch. The NXP S32K31XEVB-Q100 Evaluation Board With 32-bit Arm Cortex-M7 S32K3 MCU gives you a ready-to-run platform that lets you focus on software, not hardware headaches. Engineers often waste weeks troubleshooting power pins or missing CAN connections; this board eliminates those delays so you can move from idea to prototype in days.
NXP S32K31XEVB-Q100 Evaluation Board With 32-bit Arm Cortex-M7 S32K3 MCU
The board solves the common problem of slow development cycles caused by incomplete reference designs. When a design lacks built-in CAN FD, LIN, and USB, you spend extra time adding external modules, which adds cost and risk. This matters because automotive projects demand strict timing and safety standards. The NXP board provides all the needed interfaces on a single PCB, letting you validate code, measure performance, and debug with the free S32 Design Studio IDE in one step.
Key Features
- 32-bit Arm Cortex-M7 core for high-performance processing.
- On-board CAN FD interface for fast vehicle networking.
- Integrated LIN transceiver for legacy bus support.
- Dual high-speed USB ports for programming and debugging.
- Power supply switch supporting 12 V, 24 V, and 48 V inputs.
- MCU voltage and current measurement pins for power analysis.
- User RGB LED and two push-buttons for interactive prototypes.
- ADC rotary potentiometer for analog input testing.
- Two touch-pad electrodes for capacitive UI experiments.
- Arduino-compatible pin layout with shield expansion capability.
- SWD/JTAG debug connector compatible with S32K3 debugger.
- Free S32 Design Studio IDE and S32 Config Tool included.
Specifications
| Product |
NXP S32K31XEVB-Q100 Evaluation Board with 32-bit Arm Cortex-M7 S32K3 MCU |
| Supported Devices |
|
| Processors and Microcontrollers |
|
| S32K Auto General-Purpose MCUs |
S32K3: S32K3 Microcontrollers for Automotive General Purpose |
| K2x / KS2x USB |
K26_180: Kinetis® K26-180 MHz, Dual High-Speed and Full-Speed USBs,
2MB Flash Microcontrollers (MCUs) based on Arm® Cortex®-M4 Core
|
| Power Management |
|
| 12 V, 24 V, and 48 V SBC Solutions |
FS23: Safety System Basis Chip (SBC) Family with Power Management, CAN and LIN |
| Features |
|
| Hardware Features |
Power supply switch
MCU voltage/current measurement
User RGB LED
2x user push-buttons
ADC rotary potentiometer
2x touch pad electrode |
| Compatibility |
Arduino pinout compatible with expansion “shield” support |
| Interfaces |
On-board CAN FD
On-board LIN
SWD/JTAG debug interface for S32K3 debugger |
| Enablement |
Free of charge S32 Design Studio IDE (Eclipse, GCC and debugger) and
S32 Config Tool (pins, clocks, peripherals) with third-party compilers and debuggers
|
