NXP TJA1101 Automotive Ethernet 100BASE-T1 PHY Evaluation Board

Developing a new car electronic control unit (ECU) often needs a fast and reliable way to test Ethernet communication. Without a proper test board, engineers spend weeks wiring custom circuits, which delays the whole project. The NXP TJA1101 Automotive Ethernet 100BASE-T1 PHY Evaluation Board gives you a ready-to-use platform, so you can check 100BASE-T1 links quickly and move your design forward.

NXP TJA1101 Automotive Ethernet 100BASE-T1 PHY Evaluation Board with NXP

Speed up your ECU prototyping with a plug-and-play Ethernet test board. The NXP TJA1101 Automotive Ethernet 100BASE-T1 PHY Evaluation Board is a compact board that holds the TJA1101 PHY chip. It lets you connect a twisted-pair cable and a host controller to evaluate IEEE 100BASE-T1 performance. Engineers who need to verify Ethernet at the early design stage will find this board essential. With NXPs proven PHY, you get accurate results without writing complex code.

Key Features

• TJA1101B PHY that meets IEEE 100BASE-T1 standards.
• 40-pin standard header (2.54 mm pitch) for MII host connection.
• Pin-strapping jumper settings for quick chip configuration.
• On-board LEDs that show PHY status and link activity.
• Included twisted-pair cable for immediate testing.
• Screw-type connector for easy cable assembly.
• Supports 100 Mbps full-duplex communication over a single pair.
• Designed for rapid functional evaluation of the TJA1101.
• Compact board layout fits into most development rigs.
• Power supply range compatible with typical ECU prototypes.
