Tired of blurry video and missed speakers in your online meetings? The Panasonic AW-UE50 4K PTZ Video Conference Camera IP Indoor Ceiling Wall White HD gives you crystal-clear video and automatic tracking so every word is heard and seen. It is built for conference rooms, classrooms, and any indoor space where you need reliable, high-definition streaming without a tangled mess of cables.
Panasonic AW-UE50 4K PTZ Video Conference Camera IP Indoor Ceiling Wall White HD
Many users struggle with cameras that cannot follow a moving presenter, produce noisy images, or require several power and video cables. When a camera fails to capture the speaker, the audience loses focus and the meeting feels unprofessional. This camera solves the issue with built-in auto-tracking, a 4K sensor for sharp detail, and PoE+ that carries power, video and control over a single Ethernet cable, making installation quick and keeping the room tidy.
Benefits
- Auto-tracking keeps the speaker centered at all times.
- Quiet direct-drive motors do not disturb the conversation.
- Single-cable PoE+ reduces installation time and clutter.
- 4K sensor delivers sharp, professional-grade video.
- Privacy mode covers the lens when the camera is not in use.
Usages
Install the camera in a university lecture hall to follow a professor as they walk across the stage. Place it in a corporate boardroom for crystal-clear video during remote conferences. Use it in a retail store to monitor aisles and capture high-definition footage for loss prevention. It also works for live streaming of webinars, small concerts, or training sessions where smooth zoom and stable images are essential.
Key Features
- 24 optical zoom with 74 wide-angle view.
- Direct-drive PTZ system with 90/sec pan and tilt speed.
- AI auto-tracking that follows a single person.
- 1/2.5-type MOS sensor for true UHD video.
- Optical image stabilization for smooth motion.
- Supports HDMI, 3G-SDI and IP outputs at the same time.
- SRT and NDI|HX protocols for stable streaming.
- Web-based management interface for easy setup.
- Built-in microphone and USB video class output.
- IP66-rated white dome design for indoor ceiling or wall mounting.
Specifications
| Performance |
| Day/night mode |
Yes |
| PTZ control |
Yes |
| Connectivity technology |
Wired |
| Placement supported |
Indoor |
| Type |
IP security camera |
| Design |
| Product colour |
White |
| Mounting type |
Ceiling/wall |
| Form factor |
Dome |
| Camera |
| Camera shutter speed |
1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 s |
| Camera shutter type |
Electronic |
| White balance |
ATW, Auto, Manual |
| Pan speed |
90 °/sec |
| Pan range |
-175 - 175° |
| Tilt speed |
90 °/sec |
| Tilt angle range |
-30 - 90° |
| Minimum illumination |
3 lx |
| Camera tilt control |
Yes |
| Camera pan control |
Yes |
| Image sensor |
| Optical sensor size |
25.4 / 2.5 mm (1 / 2.5") |
| Number of sensors |
1 |
| Sensor type |
MOS |
| Lens system |
| Focus |
Motorized/Manual |
| Digital zoom |
1.4x |
| Optical zoom |
24x |
| Zoom capability |
Yes |
| Number of lenses |
1 |
| Video |
| Image stabilizer |
Yes |
| Noise reduction |
Yes |
| Video streaming |
Yes |
| Frame rate |
30 fps |
| Supported video modes |
720p, 1080i, 1080p, 2160p |
| Supported graphics resolutions |
320 x 180, 640 x 360, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Video compression formats |
H.264, M-JPEG, MP4, MPEG4 |
| Maximum resolution |
1920 x 1080 pixels |
| Audio |
| Audio formats supported |
PCM |
| Network |
| Streaming method |
Multicast, Unicast |
| Supported network protocols |
TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, DHCPv6, DNS, NTP, ICMPv6(MLD), RTSPoverTCP, RTSPoverHTTP, SSL(TLS) |
| Networking standards |
IEEE 802.3at |
| Bluetooth |
No |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Storage |
| Compatible memory cards |
MicroSD (TransFlash) |
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Ports & interfaces |
| HDMI ports quantity |
1 |
| USB port |
Yes |
| Microphone in |
Yes |
| BNC output ports |
1 |
| RS-422 ports |
1 |
| RS-232 ports |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Management features |
| Web-based management |
Yes |
| Power |
| DC output current |
1.3 A |
| DC output voltage |
12 |
| Power source type |
DC, PoE |
| Operational conditions |
| Operating relative humidity (H-H) |
20 - 90% |
| Storage temperature (T-T) |
-20 - 50 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
| Cable length |
1.5 m |
| Weight |
1.8 kg |
| Height |
192.1 mm |
| Depth |
166 mm |
| Width |
160 mm |
| Packaging data |
| Package weight |
2.05 kg |
| Supplier features |
| Manufacturer |
Panasonic |
| Packaging content |
| Mounting kit |
Yes |
| Number of cameras |
1 |
| Other features |
| Maximum resolution |
1920 x 1080 pixels |
