Switch. Fit. Click.
TOUGHBOOK 55 with Windows 11 Pro, magnesium chassis, flexible configurations and universal bay is the most versatile 14" rugged Toughbook ever built, but doesn't compromise on durability, with an unique 'honeycomb' design for improved strength and splash resistant design. In terms of flexibility, the TOUGHBOOK 55 is equally outstanding. It offers a huge array of configuration options, making it easier for customers to have exactly the device they want.
Secured-core PC compliant - the most secure Windows device in the market.
TOUGHBOOK 55 includes new advanced features which makes it compliant with a new class of secure PCs that Microsoft is developing in partnership with OEM partners. Through deep integration between hardware, firmware and Windows 11 Pro the TOUGHBOOK 55 offers the greatest protection from highly advanced
threats & increasing risks of cyberattacks, now and in the future.
The TOUGHBOOK 55 is one of the first modern Windows device in the market that comes with the highest level of hardware, software and identity protection ready right out-of-the-box.
A game changer for computing security.
This is your device, how you want it.
Add a smartcard, HF-RFID or fingerprint reader. Integrate DVD, Blu-Ray, and extra storage. Even choose an additional second battery. It’s as simple (and as fast) as: Switch. Fit. Click.
Easy and intuitive handling
Slim, lightweight, and easy to carry via its handle, the TOUGHBOOK 55 is designed to be taken anywhere. Every single detail has been developed to fit the way you work. From front cameras, a loud stereo speaker for ease of communication over sirens, and enhanced voice recognition while driving, to a dedicated GPS, backlit keyboard, and all-weather, high-brightness touchscreen.
No more device failures, downtime or disturbed work
Engineered from the ground up to be used on-the-go and in harsh environments, tested to military standard (MIL-STD 810H) and officially IP53-rated for water and dust resistance. The TOUGHBOOK 55 honeycomb design means it can also survive drops, knocks, vibrations, extreme temperatures and more.
Add in 4G LTE and dual pass-through antenna connector for optimised connectivity; plus, up to 20-hours of battery life based on Mobile Mark 25 (thanks to optional battery hot-swap), and your team will always be able communicate, access critical info and report in real time when on the move.
A more sustainable solution
Because it’s ready to adapt to the ever-changing demands of businesses and users, the TOUGHBOOK 55 is designed to last the long-haul. Add in features as your needs change in the future…without having to overhaul your entire ecosystem. Individual parts can be repaired or replaced in isolation…without affecting the unit as a whole. So, you can reduce downtime, your carbon footprint, and your budget spend.
Specifications
| Design |
| Rugged design |
Yes |
| Form factor |
Clamshell |
| Product colour |
Black |
| Product type |
Laptop |
| Display |
| Panel type |
LCD |
| HD type |
HD |
| Display resolution |
1366 x 768 pixels |
| Display diagonal |
35.6 cm (14") |
| Processor |
| Processor cache type |
Smart Cache |
| Processor cache |
12 MB |
| Efficient-core Max Turbo Frequency |
3.5 GHz |
| Performance-core Max Turbo Frequency |
4.7 GHz |
| Efficient cores |
8 |
| Performance cores |
2 |
| Processor threads |
12 |
| Processor cores |
10 |
| Processor model |
i5-1345U |
| Processor generation |
13th gen Intel® Core™ i5 |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Memory |
| Maximum internal memory |
64 GB |
| Internal memory type |
DDR4-SDRAM |
| Internal memory |
32 GB |
| Storage |
| Compatible memory cards |
MicroSDXC |
| Card reader integrated |
Yes |
| NVMe |
Yes |
| SSD capacity |
1 TB |
| Number of SSDs installed |
2 |
| Storage media |
SSD |
| Total storage capacity |
2 TB |
| Graphics |
| On-board graphics card model |
Intel Iris Xe Graphics |
| On-board graphics card family |
Intel Iris Xe Graphics |
| On-board GPU manufacturer |
Intel |
| Discrete graphics card model |
Not available |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Audio |
| Audio system |
MaxxAudio |
| Network |
| Bluetooth version |
5.3 |
| Bluetooth |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| 4G standard |
LTE |
| Mobile network generation |
4G |
| Mobile network connection |
Yes |
| Ports & interfaces |
| Combo headphone/mic port |
Yes |
| Intel® Thunderbolt 4 |
Yes |
| Thunderbolt 4 ports quantity |
1 |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Keyboard |
| Numeric keypad |
No |
| Pointing device |
Touchpad |
| Software |
| Operating system architecture |
64-bit |
| Operating system installed |
Windows 11 Pro |
| Battery |
| Battery capacity |
6500 mAh |
| Battery capacity |
6500 mAh |
| Battery voltage |
10.8 V |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Power |
| DC-in jack |
Yes |
| AC adapter output voltage |
15.6 V |
| AC adapter output current |
7.05 A |
| AC adapter input voltage |
100 - 240 V |
| AC adapter frequency |
50/60 Hz |
| Operational conditions |
| Drop proof |
91 cm |
| Operating temperature (T-T) |
-29 - 60 °C |
| Weight & dimensions |
| Height |
272 mm |
| Depth |
32.8 mm |
| Width |
345 mm |
| Weight |
2.08 kg |
| Packaging content |
| AC adapter included |
Yes |
| Other features |
| Internal memory |
32 GB |
| Manufacturer |
Panasonic |
| Maximum internal memory |
64 GB |
| Operating temperature (T-T) |
-29 - 60 °C |
