When high-performance storage needs to handle large datasets with fast NVMe access, iXsystems TrueNAS F100 provides an all-flash 2U NAS platform with 24 front-loading NVMe SSD bays. It supports up to 10 PB capacity, up to 20 PB effective capacity, 48 cores and 96 threads, and high-speed networking up to 4× 10/25/40/100 GbE or 8× 100GbE.
iXsystems TrueNAS F100 for High-Performance All-Flash Storage
iXsystems TrueNAS F100 is designed for storage environments that require high capacity, fast NVMe storage, and flexible high-speed connectivity. Its 24 × 2.5" NVMe SSD drive bays support Enterprise Class NVMe Gen4 SSDs, while distributed write logging and up to 512 GB DRAM read cache support demanding storage workloads.
Usages
iXsystems TrueNAS F100 can be used for:
-
High-performance all-flash NAS storage
-
Enterprise NVMe storage environments
-
Large-scale data storage
-
High-speed network storage
-
Storage deployments requiring Fibre Channel connectivity
-
High-capacity storage with NVMe expansion shelves
Benefits
The TrueNAS F100 combines 24 NVMe SSD bays with support for up to 10 PB maximum capacity and up to 20 PB maximum effective capacity. Its 48-core, 96-thread controller provides substantial processing capacity, while up to 512 GB DRAM read cache and distributed write logging support high-performance storage operations. High-speed networking options and Fibre Channel connectivity provide flexible connectivity for demanding enterprise environments.
Key Features
All-Flash Storage: Provides an all-flash storage platform with 24 × 2.5" NVMe SSD drive bays.
48 Cores / 96 Threads: The controller provides 48 cores and 96 threads for high-performance storage processing.
512 GB DRAM Read Cache: Supports up to 512 GB of DRAM read cache.
Enterprise Class NVMe Gen4 SSD: Supports dual-port Enterprise Class NVMe Gen4 SSD storage media with capacities from 7.6 TB to 60 TB.
10 PB Maximum Capacity: Supports up to 10 PB of maximum capacity and up to 20 PB maximum effective capacity.
High-Speed Networking: Supports up to 4× 10/25/40/100 GbE or up to 8× 100GbE optical networking.
32 Gb Fibre Channel: Provides 4 × 32 Gb Fibre Channel connectivity.
Dual Redundant Power Supplies: Includes dual redundant, hot-swappable, high-efficiency 80+ Platinum power supplies.
24-Bay 2U Design: Provides 24 × 2.5" front-loading, hot-swap NVMe SSD drive bays in a 2U chassis.
IPMI Remote Management: Includes 1x IPMI Out-of-Band Management Port and IPMI remote power on/off.
Specifications
|
| CPU |
AMD EPYC™ 7302P 16-core/32-thread processor, up to 3.3 GHz |
| CPU Architecture |
64-bit x86 |
| Encryption Engine |
(AES-NI) |
| System Memory |
256 GB RDIMM DDR4 ECC |
| Maximum Memory |
4 TB (16 x 256 GB) |
| Memory Slot |
16 x RDIMM DDR4 |
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
24 x 2.5-inch U.2 PCIe NVMe
The system is shipped without SSD.
|
| Drive Compatibility |
2.5-inch U.2 NVMe Gen 3 x4 solid state drives |
| Hot-swappable |
Supported |
| SSD Cache Acceleration Support |
Supported |
| SR-IOV |
Supported |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
| 25 Gigabit Ethernet Port |
4 x 25GbE SFP28 SmartNIC port |
| Wake on LAN (WOL) |
Only the 2.5GbE port
|
| Jumbo Frame |
Supported |
| PCIe Slot |
5
Slot 1: PCIe Gen4 x4
Slot 2: PCIe Gen4 x8 or x4
Slot 3: PCIe Gen4 x4
Slot 4: PCIe Gen4 x8
Slot 5: PCIe Gen4 x16 or x8
*Slot 4 and Slot 5 are preinstalled with 25GbE network adapters. Please reserve these slots for the 25GbE adapters for the best performance.
**Slot 2 provides the width of PCIe Gen4 x8 when Slot 3 is not in use, and provides the width of PCIe Gen4 x4 when Slot 3 is in use.
***Slot 5 provides the width of PCIe Gen4 x16 when Slot 4 is not in use, and provides the width of PCIe Gen4 x8 when Slot 4 is in use.
Card dimensions for PCIe slot 1：225 x 68.9 x 28.76 mm / 8.86 x 2.71 x 1.13 inches.
Card dimensions for PCIe slot 2：225 x 68.9 x 18.76 mm / 8.86 x 2.71 x 0.74 inches.
Card dimensions for PCIe slot 3：225 x 68.9 x 18.76 mm / 8.86 x 2.71 x 0.74 inches.
Card dimensions for PCIe slot 4：225 x 68.9 x 39.08 mm / 8.86 x 2.71 x 1.54 inches.
Card dimensions for PCIe slot 5：225 x 68.9 x 18.76 mm / 8.86 x 2.71 x 0.74 inches.
Wider cards can be installed if the next PCIe slot will not be used.
|
| USB 3.2 Gen 1 port |
2 |
| Form Factor |
Rackmount |
| LED Indicators |
HDD, Status, 10 GbE, LAN, storage expansion port status |
| Buttons |
Power, Reset |
| Dimensions (HxWxD) |
88.3 × 480.97 × 510.23 mm |
| Weight (Net) |
16.77 kg |
| Weight (Gross) |
20.95 kg |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
1100W PSU(x2), 100-240Vac,
Max Wattage:
1100W@200-240Vac
850W@100-240Vac |
| Power Consumption: Operating Mode, Typical |
277.64 W
Tested with drives fully populated.
|
| Fan |
4 x 60mm, 12VDC |
| System Warning |
Buzzer |
| Standard Warranty |
5 years |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
10000 |
