QNAP TS-h3088XU-RP, Intel Xeon W-1270, 64GB 3 PCIe Slots, Rackmount NAS

When you run a growing business, slow storage and limited network speed can hold back your team. Files take too long to load, backups stall, and video streams buffer, causing frustration and lost productivity. The QNAP TS-2483XU-RP is a high-performance rack-mount NAS designed to store massive amounts of data, deliver fast access, and keep everything secure. It gives you the power to handle demanding workloads, protect critical information, and scale as your needs expand.

QNAP TS-2483XU-RP - Enterprise-grade storage for demanding environments

This NAS solves the problem of bottlenecked data flow in busy offices or data centers. When storage cannot keep up, users experience delays, and IT teams spend extra time troubleshooting. The TS-2483XU-RP provides a clear solution with a fast Intel® Xeon® W-1270 processor, large memory capacity, and multiple high-speed network ports, ensuring smooth file transfers, rapid backups, and reliable multi-user access. It also offers hot-swappable drives and SSD cache acceleration, so you can add capacity or speed without downtime.

Benefits

• Ultra-fast processing with an 8-core/16-thread Intel® Xeon® W-1270 CPU up to 5.0 GHz, handling heavy workloads effortlessly.
• 64 GB DDR4 ECC memory (expandable to 128 GB) protects data integrity and supports many simultaneous users.
• 30 hot-swappable 2.5-inch SATA bays (24 front, 6 rear) let you store up to dozens of terabytes and replace drives on the fly.
• Dual 25 GbE ports and four 2.5 GbE ports give you high-bandwidth network connectivity for fast file sharing and video streaming.
• Built-in SSD cache acceleration improves read/write performance for frequently accessed files.

Usages

The TS-2483XU-RP fits a variety of real-world scenarios. Small-to-medium businesses can use it as a central file server, providing quick access to documents for all employees. Media teams benefit from the hardware-accelerated transcoding feature, allowing smooth playback of high-resolution video directly from the NAS. IT departments can deploy it for automated backups, disaster recovery, and virtual machine storage, thanks to its robust CPU and large memory pool. The multiple Ethernet ports also make it ideal for high-throughput environments such as surveillance systems or big-data analytics where fast data ingestion is critical.

Key Features

• Intel® Xeon® W-1270 8-core/16-thread processor, up to 5.0 GHz - delivers enterprise-level compute power.
• 64 GB UDIMM DDR4 ECC system memory, expandable to 128 GB (4 × 32 GB) - ensures stability and supports heavy multitasking.
• Four DDR4 UDIMM slots, requiring matching pairs for dual-DIMM configurations - simplifies memory upgrades.
• 5 GB flash memory for dual-boot OS protection - adds an extra layer of system reliability.
• 30 hot-swappable 2.5-inch SATA bays (24 front, 6 rear) supporting both HDDs and SSDs - provides flexible storage options.
• SSD cache acceleration support - speeds up access to frequently used data.
• Four 2.5 GbE (2.5G/1G/100M) ports and two dedicated 25 GbE ports - offers scalable high-speed networking.
• Optional 5 GbE, 10 GbE, and additional 25 GbE via adapters - lets you expand bandwidth as needed.
• Three PCIe Gen3 slots (slot 1 x8/x4, slot 2 x4, slot 3 x4) - enables extra network cards or expansion cards.
• USB 3.2 Gen 2 (10 Gbps) - two Type-C and two Type-A ports for fast peripheral connections.
• Rackmount form factor - fits standard 19-inch racks for data-center deployment.
• LED indicators for HDD, status, 10 GbE, LAN, and storage expansion - give quick visual health checks.
• Power supply: two 550 W units, 100-240 V - provides redundant power for continuous operation.
• Power consumption: 129.57 W in disk standby, 261.81 W typical operating (full drive load) - efficient for a system of this size.
• Three 60 mm fans (12 VDC) with buzzer warning - maintain cooling and alert on issues.
• Standard 3-year warranty - gives peace of mind for enterprise investment.

The QNAP TS-2483XU-RP combines raw processing power, massive storage capacity, and flexible networking into a single, reliable package. It removes the bottlenecks that slow down your workflow, protects your data with ECC memory and dual-boot flash, and grows with your business thanks to hot-swappable bays and expandable memory. Choose this NAS to keep your team productive, your data safe, and your IT infrastructure ready for tomorrow’s challenges.

Specifications
