Product Description
WisNode TrackIt (RAK2171) is RAKwireless’ latest LoRaWAN GPS tracking device. It comes in a small form factor with rechargeable battery and tracking and configuration application, available for iOS and Android devices.
RAK2171 supports multiple working modes and notification options. When used with RAK WisGate Edge gateways and in P2P mode you can monitor your tracker on the application map, create geofences, and receive SOS and movement notifications. You can also configure the WisNode TrackIt to work with any third-party LoRaWAN network using the TrackIt application as a configuration tool.
Notes: WisNode TrackIt will support all global LoRaWAN bands. For now, it supports EU868, IN865, RU864, US915, AU915, and KR920 bands. All other bands will be available with the coming firmware updates.
Key Features
- Built-in LoRaWAN, Bluetooth, and GPS
- Built-in battery: 400 mAh
- Charger with a magnetic plate
- Tracker Dimensions: 42x42x18 mm
- Tracker weight: 25 g
- Built-in accelerometer
- Operating temperature: -20° C to +60° C
- Android and iOS application for easy management, configuration, and location tracking
- IP65
Specifications:
| Product Name |
RAK2171 WisNode TrackIt |
| Product Type |
LoRaWAN GPS Tracker |
| Manufacturer |
RAKwireless |
| Wireless Technology |
LoRaWAN, Bluetooth, GPS |
| LoRa Chip |
SX1262 |
| MCU / Platform |
MT2523 with built-in Bluetooth and GPS |
| Navigation |
GPS / GLONASS |
| Bluetooth Version |
Bluetooth 4.2 |
| LoRaWAN Bands |
EU868, IN865, RU864, US915, AU915, KR920 (others via firmware) |
| Working Modes |
LoRaWAN Mode, P2P Mode, Third-party LNS |
| Sensors |
Built-in accelerometer, motion detection |
| Battery |
400 mAh rechargeable lithium battery |
| Charging |
Magnetic charging plate/contact charging |
| Transmit Power |
Up to 1 W peak |
| Operating Range |
Up to ~6 miles (LoRaWAN dependent) |
| Dimensions |
42 × 42 × 18 mm |
| Weight |
25 g |
| Operating Temperature |
-20°C to +60°C |
| Protection Rating |
IP65 |
| Mobile App |
Android & iOS TrackIt App |
| Notifications |
SOS, geofence, movement alerts |
| Gateway Compatibility |
RAK WisGate Edge & third-party LoRaWAN networks |
| Additional Features |
Small form factor, low power tracking, map monitoring, geofencing |
