Robustel R1520LG Industrial LoRaWAN IoT network Gateway with 4G/LTE & Wi-Fi

Robustel R1520LG LoRaWAN gateway with 4G/LTE, Wi-Fi and integrated LNS

The Robustel R1520LG is an industrial LoRaWAN gateway engineered for building-scale and plant deployments. It combines 4G/LTE cellular and Wi-Fi backhaul with PoE-PD power, letting you place the gateway where RF performance is best.

Deploy with your preferred architecture: connect to external LNS platforms via UDP, LoRa Basics Station, or LORIOT. Alternatively run the embedded ChirpStack server for full on-device control and send data straight to AWS or Azure using the Edge2Cloud ChirpStack connector with built-in buffering.

Two Ethernet ports (WAN/LAN), dual-SIM, and RS-232 / RS-485 simplify integration with existing controllers and BMS/SCADA networks.

Based on Debian Linux, the R1520LG can also host applications and when paired with Edge2Cloud Modbus, aggregate wired and LoRa sensors at the edge. Fleet operations are streamlined through RCMS Device Management and RobustVPN allows secure remote access from anywhere in the world.

Key Features:

• Support PoE-PD for optimal gateway location
• Wi-Fi client and AP modes
• Wide power input ranging from 9 to 60VDC
• Dual Ethernet ports for WAN and LAN connections
• Dual SIM slots for resilient cellular communication
• RS-232 and RS-485 ports for peripheral connection
• Utilize the “Operations Console” for robustgateway management
• Offer RobustVPN for easy remote access to all gateways, regardless of SIM or internet connection type
• Integrate “E2C Chirpstack” for seamless LoRa data connectivity to AWS/Azure or other cloud platforms
• Enable data buffering for LoRa data via“E2C Chirpstack,” a feature not typically found in standard LoRa gateways

Frequency Bands (Same for All Models)

4G: LTE FDD: B1/2/3/4/5/7/8/12/13/ 18/19/20/25/26/28/66
LTE TDD: B34/B38/39/40/41
3G: WCDMA: B1/2/4/5/6/8/19
2G: GSM: B2/3/5/8

Specifications:

Ordering Information
