If you are looking for a reliable and fast internet connection for your business or industrial application, you may have noticed that traditional routers often struggle to provide a stable and secure connection. This can lead to downtime, lost productivity, and decreased efficiency. The Robustel R5010 Industrial 5G Router with 2.5GB LAN, PoE-PD and USB Connectivity is designed to solve this problem by providing a robust and secure internet connection that can handle the demands of industrial applications. With its advanced features and reliable performance, this router is the perfect solution for businesses that require a fast and stable internet connection.
Robustel R5010 Industrial 5G Router with 2.5GB LAN, PoE-PD and USB Connectivity with Robustel
Imagine having a router that can provide a fast and reliable internet connection, even in the most demanding industrial environments. The Robustel R5010 Industrial 5G Router with 2.5GB LAN, PoE-PD and USB Connectivity is designed to provide just that. With its advanced features and robust design, this router is the perfect solution for businesses that require a secure and stable internet connection. Whether you are looking to connect your industrial equipment, provide internet access to your employees, or simply need a reliable connection for your business, the Robustel R5010 is the perfect choice.
Benefits
- Fast and reliable internet connection, reducing downtime and increasing productivity
- Advanced security features, providing a secure connection for business operations
- Robust design, capable of withstanding the demands of industrial environments
- Easy to install and configure, reducing setup time and costs
- Support for a variety of industrial applications, including manufacturing, transportation, and energy management
Key Features
- 2.5GB LAN, providing fast and reliable internet connection
- PoE-PD, providing power over Ethernet, reducing the need for additional power sources
- USB Connectivity, providing a convenient way to connect devices
- Advanced security features, including firewall, VPN, and intrusion detection
- Robust design, capable of withstanding the demands of industrial environments
- Support for a variety of industrial applications, including manufacturing, transportation, and energy management
- Easy to install and configure, reducing setup time and costs
- Support for 5G, 4G, and 3G networks, providing a reliable connection in a variety of environments
- CE, UKCA, CB, and RCM certifications, ensuring compliance with industry standards
- 1 x DIN Rail Mounting Kit, 4 x Cellular Antenna, and 1 x Power Adapter, providing everything needed for installation
Specifications
| Cellular Interface |
|
| Number of antennas |
4 (ANT0 + ANT1 + ANT2 + ANT3) |
| Connector |
SMA-K |
| SIM |
2 x Mini SIM (2FF) |
| Ethernet Port |
|
| Number of ports |
1 x 2.5 Gbps, LAN |
| Supporting |
802.3at PD feature on ETH |
| Magnet isolation protection |
1 KV |
| Others |
|
| Reset button |
1 x RST |
| USB port |
1 x USB 3.1 (Type C) For power supply, network supply and debug |
| LED indicators |
1 x RUN, 1 x MDM, 1 x USR, 1 x RSSI |
| Watchdog |
External |
| Power Supply and Consumption |
|
| Connector |
4-pin Micro-Fit socket |
| Input voltage |
12/24/48 V DC, 9 ~ 60 V DC |
| 5 V/3 A by USB Type C Port |
Reverse polarity protection, surge protection |
| PoE-PD voltage |
Possibility to power up through ETH |
| |
44 ~ 57 V DC |
| Power consumption |
Idle: 1.5 W@12 V Max: 15 W@12 V |
| Recommended power supply |
12 V DC/1.5 A power adapter |
| Physical Characteristics |
|
| Ingress protection |
IP30 |
| Housing & Weight |
Aluminum, 276 g |
| Dimensions |
30 x 94 x 100 mm |
| Installations |
Desktop, wall mounting and 35 mm DIN rail mounting |
| Operating temperature |
-40 ~ +70 °C |
| Storage temperature |
-40 ~ +85 °C |
| Relative humidity |
5 ~ 95% RH (non-condensing) |
| Software (Basic features of RobustOS) |
|
| Network protocols |
PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, DNS, NTP,SMTP, Telnet, VLAN, HTTPs, ARP, SSH2, DDNS, etc. |
| VPN tunnels |
IPsec, OpenVPN, GRE, WireGuard |
| Firewalls |
DMZ, anti-DoS, Filtering (IP/Domain name/MACaddress), Port Mapping, Access Control |
| Remote management |
Web, CLI, SMS |
| Others |
Smart Roaming V3 |
| SDK |
|
| Supported programming languages |
C, C++ |
| Flash available for SDK |
10 MB |
| RAM available for SDK |
45 MB |
| Order Information |
|
| Model |
R5010-A-5G-A28EU |
| Code |
A011300001 |
| Bands |
5G: NR SA/NSA: n1/3/5/7/8/20/28/38/40/41/75/76/77/78
4G: LTE FDD: B1/3/5/7/8/20/28/32
LTE TDD: B38/40/41/42/43
3G: WCDMA: B1/5/8 |
| Region |
EMEA+ANZ |
| Certifications |
CE, UKCA, CB, RCM |
| Package content |
1 x R5010 Router (B Code: B113001), 1 x DIN Rail Mounting Kit,
4 x Cellular Antenna 1 x Power Adapter
|
