Seatronx SRT-24W-1080, 1920x1080 Pixels 24" Industrial Monitor
Seatronx SRT-24W-1080, 1920x1080 Pixels 24" Industrial Monitor is a 24-inch industrial display designed for applications that require clear Full HD visuals, reliable operation, and flexible installation. It features a 24.0-inch active area with a native resolution of 1920 x 1080 pixels and supports 16.7M colors, making it suitable for industrial monitoring, control interfaces, marine workstations, and other professional display applications.
The monitor provides a 1000 cd/m² sunlight-readable brightness option for SRT configurations and 350 cd/m² brightness for Pilot House applications. Its 1000 contrast ratio and 89.89° viewing angle on the left, right, up, and down help provide clear screen visibility from different viewing positions. A 50000-hour backlight lifetime supports long-term display operation.
The SRT-24W-1080 supports HDMI, DVI, VGA, and Component input terminals, allowing it to connect with a variety of video sources and industrial systems. It also features red night mode, which can support display use in environments where reduced visual disturbance is required. Backlight dimming from 0 to maximum provides additional control over screen brightness.
Designed for flexible integration, the monitor supports panel mount and VESA mounting options. Its front dimensions are 539.3 x 403.8 x 61mm, while the cutout dimensions are 520.3 x 377 x 61mm. Projected capacitive touch and optical bonding are included, while remote control is available as an optional feature, providing additional functionality for compatible installations.
The monitor operates from a 9-34V power source with an isolated 9-34V voltage converter and uses a screw terminal inlet plug. Power consumption is specified as SRT 3.5 / PHT 1.8 AMPS @ 24VDC, with an optional AC power supply available. With an operating temperature range of 0 to 50°C and storage temperature range of -20 to 60°C, the Seatronx SRT-24W-1080 provides a practical display solution for industrial and marine environments.
Key features
• 24.0-inch industrial display with 1920 x 1080 native resolution
• 16.7M colors with 1000 contrast ratio
• 1000 cd/m² sunlight-readable SRT brightness
• HDMI, DVI, VGA, and Component input terminals
• Red Night Mode and 0 - max backlight dimming
• Projected capacitive touch and optical bonding
• Panel mount and VESA mounting options
• 9-34V power input with isolated voltage converter
SPECIFICATION
| Diagonal (active area) |
24.0 inch |
| Native Resolution |
1920 x 1080 Pixels |
| Colors |
16.7M |
| Contrast Ratio |
1000 |
| Brightness Sunlight Readable (SRT) |
1000 cd/m² |
| Brightness Pilot House (PHT) |
350 cd/m² |
| Viewing Angle (left, right) |
89.89° |
| Viewing Angle (up, down) |
89.89° |
| Backlight Lifetime |
50000 hrs |
| Backlight Dimming |
0 - max |
| Red Night Mode |
YES |
| Input Terminal |
HDMI/DVI/VGA, Component |
| Power Source |
9-34V + and - |
| Voltage Converter |
9-34V (isolated) |
| Power Consumption |
SRT 3.5 / PHT 1.8 AMPS @ 24VDC |
| Inlet Plug |
Screw Terminal |
| Optional AC Power Supply |
YES |
| Dimensions (Front) |
539.3 x 403.8 x 61mm (21.18 x 15.89 x 2.28") |
| Cutout Dimensions |
520.3 x 377 x 61mm (20.47 x 12.88 x 2.40") |
| Sealing Front |
UGB with potentiometer |
| Mounting |
Panel mount/VESA |
| Operating Temperature |
0 to 50°C |
| Storage Temperature |
-20 to 60°C |
| Parameter Adjustment |
Front knob and pad at back-side |
| Power On/Off |
Front knob and pad at back-side |
| Projected Capacitive Touch |
YES |
| Optical Bonding |
YES |
| Remote Control |
Optional |
| Description |
SRT-24W-1080 24" Wide Screen 1920x1080 Sunlight readable
touch screen display, 9-36vdc, 1 HDMI, 1 DVDI, 1 VGA, 1
Composite, wide dimming range
|
