| Core Parameters |
|
| CPU |
RK3588, octa-core, with a maximum main frequency of 2.4GHz |
| GPU |
Quad-core Mali-G610 MP4 GPU, supporting up to 8K@60fps H.265/VP9 video decoding and
8K@30fps H.265/H.264 video encoding, with support for simultaneous encoding and decoding.
It can achieve up to 32-channel 1080P@30fps decoding and 16-channel 1080P@30fps encoding
|
| Storage |
64GB |
| DDR Memory |
8GB |
| Internet |
|
| WiFi Support |
WiFi6 |
| Bluetooth |
BT5.0 |
| 4G |
Supports 4G module for Internet access |
| Ethernet |
2-way 10M/100M/1000M adaptive Ethernet |
| Antenna |
|
| Antenna Interfaces |
2 SMA antenna interfaces |
| WiFi Antennas |
2 * WiFi antennas |
| Display Interface |
|
| HDMI OUT |
Supports 2-way HDMI output, with a maximum support of 8K@60Hz output, and only 1-way can
output 8K@60Hz at the same time
|
| HDMI IN |
Supports 1-way HDMI input, with a maximum support of 1080p@60Hz |
| External Ports |
|
| USB 3.0 |
1 x USB3.0 (current-limited to 1.5A) |
| USB 2.0 |
2 x USB2.0 (current-limited to 1A) |
| USB-OTG |
1 x USB3.0 (default OTG, current-limited to 1.5A) |
| Audio Interface |
1 x LINE IN, 1 * LINE OUT, using a 3.5mm, three-segment headphone jack |
| RS232 |
1 x RS232 interface, using a DB9 interface |
| RS485 |
1 x RS485 interface, built-in the DB9 (COM1) interface |
| I/O |
2-way GPIO, with 1-way input and 1-way output by default, built-in the DB9 (COM1) interface |
| Optional Customization |
The SW switch position can be customized for interfaces |
| SIM Card |
|
| SIM Card Interface |
1 x Nano-SIM card interface, supporting various standards (depending on the 3G/4G module) |
| Nano SIM Card Size |
12mm x 9mm |
| Execution Standard |
ETSI TS 102 221 V11.0.0 |
| Internal Ports |
|
| Internal USB 2.0 |
1 * USB2.0 (current-limited to 1A) |
| Mini PCI-e |
Built-in PCI-E 4G module interface. Supports various PCI-E 4G modules such as Huawei, ZTE, and
Longshang, and supports Internet access
|
| M.2 SSD (Optional) |
Supports built-in M.2 SSD |
| SATA |
Supports 1-way standard SATA interface, following the SATA3.0 interface specification. It
supports multiple SATA hard drives with a maximum transmission rate of 6Gbps/s (750MB/s)
|
| SATA Power |
Supports 12V/5V input and does not support 3.3V power supply |
| Power Supply |
|
| Input Voltage |
DC 12~24V（±10%） |
| Static Power Consumption |
20W（TYP.） |
| Fan / Environmental Parameters |
|
| Operating Temperature |
0℃~60℃ |
| Operating Humidity |
8% - 90%RH, no condensation |
| Storage Temperature |
-20℃ - 70℃ |
| Storage Humidity |
10%~95%RH |
| Reliability |
|
| Vibration Protection |
IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
| Shock Protection |
IEC 60068-2-27, half-sine wave, lasting 11ms |
| EMS Electrostatic Immunity |
GB17626.2-2018 IEC61000-4-2 Level 4 standard, Contact discharge 4KV/Air discharge 8KV |
| EMS Lightning Surge |
GB17626.5-2019 ±2KV |
| Certification / Waterproof / Appearance Information |
|
| Size |
136(H) × 126.2(W) × 43(D) mm |
| Appearance Color |
Black matte shell |
| Supported Installation Methods |
Horizontal placement or wall-mounted installation |
