SIMCom A7602E-H-M2 4G Module
A7602E-H-M2 is the LTE Cat 4 module which supports wireless communication modes of LTE-TDD/
LTE-FDD/HSPA+/GSM/GPRS/EDGE. It supports maximum 150Mbps downlink rate and 50Mbps uplink rate.
A7602E-H-M2 adopts M.2 form factor and greatly facilitates compatible product design for the customer needs.
A7602E-H-M2 supports multiple built-in network protocols, supports drivers for main operation systems (USB driver for Windows, Linux and Android etc.) . Meanwhile A7602E-H-M2 is with powerful expansibility, including abundant interfaces such as UART, USB, GPIO, which is suitable for main IoT applications such as telematics, surveillance devices, CPE, industrial routers, and remote diagnostics etc.
Advantages
- M.2 form factor with compatibility
- Suitable for LTE, UMTS and GSM networks
- Abundant software functions: FOTA, LBS, SSL
General Features
- Frequency Bands:
- LTE-TDD B38/B40/B41
- LTE-FDD B1/B3/B5/B7/B8/B20/B28
- UMTS/HSPA+ B1/B5/B8
- GSM/GPRS/EDGE 900/1800 MHz
- Supply Voltage: 3.135V ~ 4.4V, Typ: 3.3V
- Control Via AT Commands
- Operation temperature: -20℃ ~ +70℃
- Dimensions: 30.0*42.0*2.3mm
- Weight: 6.1±0.2g
Data Transfer
- LTE Cat 4: Uplink up to 50Mbps
- Downlink up to150Mbps
- HSPA+: Uplink up to 5.76Mbps
- Downlink up to 21.6 Mbps
- UMTS: Uplink/Downlink up to 384Kbps
- EDGE: Uplink/Downlink up to 236.8Kbps
- GPRS: Uplink/Downlink up to 85.6Kbps
Interfaces
- USB2.0
- UART
- (U)SIM card(1.8V/3V )
- PCM
- WoWWAN
- W_DISABLE
- I2C
- GPIO
- Antenna: Primary/Diversity/GNSS*
Other Features
- USB Driver for Microsoft Windows 7/8/10
- USB Driver for Linux /Android
- RIL supporting for Android 5.0/6.0/7.0/8.0/9.0/10.0/11.0/12.0
- Firmware update via USB/FOTA
- TCP/IP/IPV4/IPV6/MultiPDP/FTP/FTPS/HTTP/
- HTTPS/DNS
- RNDIS/PPP/ECM/MBIM
- SMS
- SSL
