SIMCom A7908E-M2 4G LTE-A Module
A7908-M2 is a Multi-Band LTE-FDD/LTE-TDD/HSPA+ module which supports Category 6 with CA and MIMO.
With a rich protocols, it is integrated with interfaces such as PCIe, USB3.0, GPIO etc. This module provides applications with great flexibility and ability of integration.
A7908-M2 adopts M2 form factor. AT commands of A7908- M2 are compatible with SIM79XX series modules. This also minimizes costs for customer and shortens time to market.
It is designed for applications that need huge data transmission in various wireless situations. Due to its high efficiency, security and flexibility, this module suits various applications.
Advantages:
- M2 form factor with various interfaces
- Huge data transmission
- AT commands of A7908-M2 compatible with SIM79XX series modules
Specifications:
| Product |
A7908E-M2 |
| Form Factor |
M2 |
| Dimensions(mm) |
42.0*30.0*2.3 |
| Frequency Bands |
|
| LTE-FDD |
B1/B3/B5/B7/B8/B20/B28/B32 |
| LTE-TDD |
B38/B40/B41/B42*/B43* |
| WCDMA |
B1/B5/B8 |
| MIMO |
4x2 MIMO |
| Temperature |
-30℃ ~ +70℃
|
| Electrical Features |
|
Supply Voltage(V)
|
3.135 ~ 4.4 |
Data Transfer
|
|
LTE
|
300Mbps(DL)/100Mbps(UL) |
HSPA+
|
42Mbps (DL)/11.2Mbps(UL) |
Software Features
|
|
| Protocol |
TCP/IP/IPV4/IPV6/Multi- PDP/FTP/FTPS/HTTP/HTTPS/MQTTS/DNS/SSL3.0 |
| TLS |
Supported |
| File System |
Supported |
| FOTA |
Supported |
| Android RIL |
Android 6/7/8/9/10/11/12 |
| USB Driver |
Microsoft Windows Win7/Win8/Win10/Win11/Linux/Android |
| MBIM |
Win8/Win10/Win11 |
| NDIS |
Linux/Win7/Win8/Win10/Win11 |
| Firmware Upgrade |
USB |
| Interfaces |
|
| SIM Card |
1.8V/2.95V |
| USB |
Supported |
| PCM |
Supported |
| I2C |
Supported |
| Diversity Receiver |
Supported |
| Certifications |
|
| Regulatory |
ROSH*/REACH*/CE*/UKCA*/RCM* |
