SIMCom SIM7600A-PCIE 4G LTE Module

Tired of unreliable cellular connections in your IoT project? The SIMCom SIM7600A-PCIE 4G LTE Module gives you fast, stable data wherever you need it. It plugs into a mini-PCIe slot and turns any board into a full-featured LTE device. If you have been struggling with dropped packets or slow upload speeds, this module solves that problem with Cat-1 speeds up to 10 Mbps down and 5 Mbps up.

SIMCom SIM7600A-PCIE 4G LTE Module

Many developers need a cellular link that works on both LTE-FDD and LTE-TDD networks, but most modules require extra boards or complex wiring. Without a solid link, remote sensors lose data, and machines cannot be monitored in real time. The SIMCom SIM7600A-PCIE answers this need by offering a compact mini-PCIe form factor that includes LTE, HSPA+, GSM and a built-in GNSS receiver. It connects directly to your host board, provides up to 10 Mbps downlink, and supports standard AT commands, so you can get online quickly and keep your device running reliably.

Usages of SIMCom

The module fits perfectly in telematics units that track fleet vehicles, in surveillance cameras that need live video streaming, and in customer-premises equipment that brings broadband to remote sites. It also works in industrial routers, smart meters, and remote diagnostic tools where a stable LTE link and accurate GPS are essential. Because it supports UART, USB and GPIO, you can embed it in any Linux, Windows or Android based system without redesigning the hardware.

Benefits

• Fast LTE Cat-1 speeds keep your data flowing without delays.
• Built-in GNSS gives precise location for tracking and navigation.
• Mini-PCIe size saves space and simplifies board design.
• Wide band support works in most countries and carriers.
• Standard AT commands let you program the module with familiar tools.

Key Features

• Mini-PCIe form factor for easy integration.
• LTE-FDD (B2/B4/B12) and LTE-TDD support.
• HSPA+ and GSM/EDGE fallback for global coverage.
• Multi-constellation GNSS receiver for accurate positioning.
• Up to 10 Mbps downlink and 5 Mbps uplink.
• Supply voltage 3.0 V - 3.3 V, operating from -40 C to +85 C.
• UART, USB, GPIO, I2C and optional PCM interfaces.
• Full TCP/IP, IPv4/IPv6, FTP, HTTP/HTTPS, DNS protocols.
• Supported TLS, FOTA, LBS, VoLTE and jamming detection.
• Drivers for Windows, Linux and Android, plus Android RIL support.

Specifications
