Next-Gen Performance and Efficiency
Combining class-leading performance and performance optimizations for real-world IO conditions, the Solidigm D7-PS1010 accelerates enterprise and cloud workloads such as AI/ML, HPC, databases, general purpose servers, and more. Designed for the long run, the D7-PS1010 delivers up to 90% IOPS consistency across the life of the drive.
PCIe 5.0 Performance Done Right
With powerful PCIe 5.0 performance, Solidigm D7-PS1010 accelerates a wide range of cloud and enterprise applications. Built to excel at every stage of the AI data pipeline, the Solidigm D7-PS1010 provides up to 50% higher throughput in certain pipeline phases.
Storage Optimized for the AI Era
Artificial Intelligence is everywhere and it’s creating higher demands for data infrastructure performance and efficiency. Our leading combination of high capacity and high- performance drives helps our partners save power and space. Step up your AI workloads with the Solidigm SSD portfolio optimized for the AI era.
Unmatched Performance Efficiency
With class-leading performance and up to 70% better IOPS/watt than leading competitors, the Solidigm D7-PS1010 improves operational efficiency without sacrificing performance. This drive delivers world-class consistency, quality, and reliability.
Fast and Flexible
Whether it’s a PCIe 5.0 or PCIe 4.0 solution, the class-leading performance of the Solidigm D7-PS1010 accelerates a wide range of workloads. Available in U.2 and E3.S form factors, these products enable both legacy and modern chassis designs to realize their fullest value.
Specifications
| Miscellaneous |
| Miscellaneous / MTBF |
2,500,000hours |
| Dimensions & Weight |
| Dimensions & Weight / Weight |
4.23oz |
| Service & Support |
| Service & Support / Type |
5-year warranty |
| Hard Drive |
| Hard Drive / Form Factor (Short) |
E3.S |
| Hard Drive / Internal Data Rate |
14500MBps |
| Hard Drive / Form Factor (Short) (metric) |
E3.S |
| Hard Drive / 4KB Random Read |
2750000IOPS |
| Hard Drive / Capacity |
15.36TB |
| Hard Drive / Internal Data Rate (Write) |
9300MBps |
| Hard Drive / Form Factor |
E3.S |
| Hard Drive / Hard Drive Type |
Internal hard drive |
| Hard Drive / Interface |
PCI Express 5.0 x4 (NVMe) |
| Hard Drive / Form Factor (metric) |
E3.S |
| Storage |
| Storage / Type |
Solid state drive |
| Header |
| Header / Product Line |
Solidigm D7-PS1010 Series |
| Header / Packaged Quantity |
1 |
| Manufacturer Warranty |
| Manufacturer Warranty / Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
| Environmental Parameters / Min Operating Temperature |
32 °F |
| Environmental Parameters / Max Operating Temperature |
170.6 °F |
| Environmental Parameters / Vibration Tolerance (operating) |
2.17 g @ 5-700 Hz |
| Environmental Parameters / Shock Tolerance (operating) |
1000 g @ 0.5 ms |
| General |
| General / Capacity |
15.36 TB |
| General / Weight |
4.23 oz |
| General / Interface |
PCI Express 5.0 x4 (NVMe) |
| General / Device Type |
Solid state drive - internal |
| General / Form Factor |
E3.S |
| Expansion & Connectivity |
| Expansion & Connectivity / Interfaces |
1 x PCI Express 5.0 x4 (NVMe) |
| Expansion & Connectivity / Compatible Bay |
E3.S |
| Performance |
| Performance / 4KB Random Write |
380000 IOPS |
| Performance / 4KB Random Read |
2750000 IOPS |
| Performance / Internal Data Rate |
14500 MBps (read) / 9300 MBps (write) |
| Performance / SSD Endurance |
28 PB |
| Reliability |
| Reliability / MTBF |
2,500,000 hours |
| Power |
| Power / Power Consumption |
23 watt (active) ¦ 5 watt (idle) |
| Summary Details |
| SSD capacity |
15.36 TB |
| SSD form factor |
E3.S |
| Component for |
Server/workstation |
