Solidigm D5-P5336, 122.88TB E1.L PCIe 4.0 x4 NVMe Solid State Drive
The Solidigm D5-P5336 is a high-capacity NVMe solid state drive designed for data center storage environments that require large amounts of storage in a compact enterprise drive. With a 122.88TB capacity, E1.L 9.5mm form factor, and PCIe 4.0 x4 NVMe interface, it provides a high-density storage option for systems handling large datasets.
The drive uses Floating Gate technology and supports sequential bandwidth of up to 7000MB/s for read operations and 3000MB/s for write operations. It also provides up to 900,000 IOPS for random reads and 19,000 IOPS for random writes under the specified test conditions. These performance characteristics make it suitable for storage systems that need high throughput and large capacity.
The Solidigm D5-P5336 is designed for enterprise workloads where storage endurance and long-term operation are important. It has an endurance rating of 0.6 DWPD (32K RW) / 134.3 PBW and a mean time between failures of 2 million hours.
Power consumption is specified at 24W during active operation and 5W when idle. The drive also provides read latency of 8μs for 4K blocks and write latency of 21μs for 32K blocks. These specifications help define its performance and power characteristics when integrated into compatible enterprise storage platforms.
The D5-P5336 is suitable for data center storage, high-capacity enterprise servers, large-scale data repositories, and other applications requiring high-density NVMe storage. Its operating temperature range of 0 - 70°C, vibration specifications, and 1,000 G maximum shock rating provide additional specifications for deployment in demanding storage environments.
Key Features
-
122.88TB storage capacity for high-density enterprise storage
-
E1.L 9.5mm form factor for data center storage systems
-
PCIe 4.0 x4, NVMe interface
-
Floating Gate technology
-
Up to 7000MB/s sequential read bandwidth
-
Up to 3000MB/s sequential write bandwidth
-
Up to 900,000 IOPS random read performance
-
134.3 PBW endurance rating
-
2 million hours mean time between failures (MTBF)
-
24W active and 5W idle power consumption
Specifications
| Key Attributes |
|
| Capacity |
122.88TB |
| Form Factor |
E1.L 9.5mm |
| Interface |
PCIe 4.0 x4, NVMe |
| Technology |
Floating Gate |
| Performance Specifications |
|
| Sequential bandwidth - 100% read (up to) |
7000MB/s |
| Sequential bandwidth - 100% write (up to) |
3000MB/s |
| Random read (100% span) |
900,000 IOPS (4K, QD256) |
| Random write (100% span) |
19,000 IOPS (32K, QD256) |
| Latency - Read |
8μs (4K Blocks) |
| Latency - Write |
21μs (32K Blocks) |
| Power - Active |
24W |
| Power - Idle |
5W |
| Reliability |
|
| Endurance Rating |
0.6 DWPD (32K RW) / 134.3 PBW |
| Mean time between failures (MTBF) |
2 million hours |
| Uncorrectable bit error rate (UBER) |
<1 sector per 10^17 bits read |
| Vibration - Operating |
2.17 GRMS (5 - 700 Hz) Max |
| Vibration - non Operating |
3.13 GRMS (5 - 800 Hz) Max |
| Shock |
1,000 G (Max) at 0.5 msec |
| Operating temp range |
0 - 70°C |
