| Ports & interfaces |
|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| Hub interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Ports quantity |
4 |
| Features |
|
| Cable length |
0.3 m |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery revision |
3.0 |
| USB Power Delivery up to |
100 W |
| Housing material |
Plastic |
| Product colour |
Grey |
| Data transfer rate |
5000 Mbit/s |
| Network |
|
| UASP support |
Yes |
| Power |
|
| Output current |
0.9 A |
| Output voltage |
5 V |
| Power consumption (typical) |
15 W |
| Power supply type |
USB |
| System requirements |
|
| Other operating systems supported |
Android |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Weight & dimensions |
|
| Weight |
41 g |
| Height |
14 mm |
| Depth |
42 mm |
| Width |
75 mm |
| Packaging data |
|
| Package weight |
94 g |
| Package height |
30 mm |
| Package depth |
175 mm |
| Package width |
142 mm |
| Operational conditions |
|
| Operating relative humidity (H-H) |
5 - 85% |
| Storage temperature (T-T) |
-5 - 70 °C |
| Operating temperature (T-T) |
0 - 45 °C |
| Sustainability |
|
| Sustainability compliance |
Yes |
| Logistics data |
|
| Products per master (outer) case |
60 pc(s) |
| Master (outer) case height |
310 mm |
| Master (outer) case length |
330 mm |
| Master (outer) case width |
530 mm |
| Technical details |
|
| Data transfer rate |
5000 Mbit/s |
| Compliance certificates |
RoHS |
| Other features |
|
| Chipset |
Fresco - FL7102, Fresco - FL5001 |
