Product Code: CNTR-226
MPN #: HD293
Imagine driving and knowing every angle of your journey is saved in crystal clear video. The Stonkam HD29, 1080P Waterproof Hard Disk Box, 4G 8CH Vehicle DVR System records up to eight high-definition cameras and stores the footage safely even in rain or dust. Many drivers lose evidence after an accident because their recorder cannot handle harsh weather or multiple feeds. This device gives you reliable proof when you need it most.
The biggest problem for fleet owners and private drivers is missing video when a crash or theft occurs. Without clear footage, insurance claims stall and legal disputes grow. This matters because every minute of lost video can cost money and peace of mind. The Stonkam system solves the issue by capturing up to eight 1080P streams, protecting the unit with waterproof housing, and adding 4G connectivity for remote access. You get instant, reliable evidence wherever the road takes you.
| System | |
| Operating System | Linux |
| Operating Interface | Graphical menu operation interface(OSD) |
| Video Permission | Administrator & user setting |
| Video | |
| Video Input | Max 8ch 1080P analog high definition |
| CVBS Output | 1CH 6pin aviation connector output PAL/NSTC |
| HD Output | 1CH 1080P |
| Video Display | 1 or 4 or 8CH |
| Video Standard | PAL: 25FPS, NTSC: 30FPS |
| Compression | H.264 main profile |
| Total Resources | 1080P PAL: 200FPS; NTSC: 240FPS |
| Audio | |
| Audio Input | 8 channels |
| Audio Output | 2 channels |
| Record Format | Synchronized video & audio recording |
| Audio Compression | ADPCM |
| Digital Processing & Storage | |
| Video Quality | 1~8 level adjustable |
| Video Bit Rate | 128kbps~6Mbps/channel |
| Audio Bit Rate | 32kbps |
| Storage | 2.5 inch SATA SSD x 1, max 2TB; SD card x 1, max 128GB |
| Alarm | |
| Alarm Input | 8 channels |
| Alarm Output | 2 channels |
| Motion Detection | High / Low / Off |
| Interface for Communication | |
| IR | 1 channel |
| RS232 | 2 channels |
| RS485 | 2 channels |
| CAN | 1 channel |
| RJ45 | 1 channel |
| USB2.0 | 1 channel |
| USB3.0 | 1 channel for file backup and firmware upgrade |
| Wireless | |
| 3G/4G | HSPDA/EVDO/FDD-LTE/TDD-LTE module optional |
| WIFI | optional |
| WIFI Hotspot/AP | optional |
| G-Sensor/Gyroscope | Available |
| Software | |
| Windows Client | Available |
| iOS Client | Available |
| Web Portal | Available |
| Power | |
| Input | 10~32V |
| Output | 12V@4A |
| Max Power Consumption | 60W |
| Standby Power Consumption | 100mW |
| Electrical Specifications | |
| Operating Temperature & Humidity | -20~70℃<80% |
| Clock | Built-in clock, Calendar |
| Super Capacitor | Available |
| Video Input Impedance | 75ohm |
| Video Output Voltage | 1Vpp CVBS output |
