When large-scale storage needs to support dozens of drives without taking up excessive rack space, Synology HD6500 provides a 4U rackmount NAS server designed for high-density storage. It supports up to 60 devices, includes dual Intel Xeon Silver 4210R processors, 64 GB DDR4 memory, and provides 960GB of installed SSD storage with RAID 5 hot spare support.
Synology HD6500 for High-Density NAS Storage
Synology HD6500 is a 4U rackmount NAS server designed for environments requiring a large number of storage devices. With support for up to 60 devices, dual Intel Xeon Silver 4210R processors, 64 GB installed DDR4 memory, and 10 Gigabit Ethernet connectivity, it provides a high-capacity platform for centralized network storage and demanding business workloads.
Usages
Synology HD6500 can be used for:
-
High-density NAS storage
-
Centralized business file storage
-
Large-scale network storage deployments
-
iSCSI storage environments
-
Rackmount data storage
-
SSD-based storage configurations
Benefits
The high-density chassis supports up to 60 devices, making the Synology HD6500 suitable for storage environments that need substantial drive capacity in a single system. Dual Intel Xeon Silver 4210R processors provide a 20-core processing configuration, while 64 GB DDR4 memory supports demanding storage workloads. Its 10 Gigabit Ethernet connectivity enables high-speed network access, and RAID 5 hot spare support provides a storage configuration designed for data availability.
Key Features
60 Supported Devices: Supports up to 60 devices in a high-density 4U rackmount chassis.
Dual Intel Xeon Silver 4210R Processors: Includes 2 x Xeon Silver 4210R 2.4 GHz processors with 10 cores each.
64 GB DDR4 Memory: Includes 64 GB installed memory with support for up to 512 GB.
960GB Total Storage: Includes 2 × 480GB SSDs for 960GB of total installed storage.
RAID 5 Hot Spare: Uses RAID 5 hot spare storage configuration with a Serial ATA-600 interface.
10 Gigabit Ethernet: Provides Gigabit Ethernet / 10 Gigabit Ethernet host connectivity.
1600 watt Power Supply: Uses an internal power supply providing 1600 watt of power.
4U Rackmount Enclosure: Uses a rack-mountable 4U enclosure measuring 6.9in × 19in × 40.2in.
5-year Warranty: Includes limited warranty and 5-year service and support.
High-Density Synology Platform: Part of the Synology High Density product line and designed for large-scale NAS storage.
Specifications:
| Chassis |
|
| Supported Devices |
60 |
| Installed Devices |
2 |
| Miscellaneous |
|
| Color Category |
Black |
| Processor |
|
| Type |
Xeon Silver |
| Processor Number |
4210R |
| Networking |
|
| Remote Management Protocol |
SNMP, Telnet, HTTP, HTTPS, SSH |
| Features |
Firewall protection, WOL, E-mail alert, print server, IPv6 support, firmware upgradable, MySQL server, web server, backup server, file sharing, ADS, SSH support, iTunes server, Samba support, FTP server, SMS alert, BitTorrent Client, e-mail server, UPnP Media Server, DLNA Media Server, Apple Time Machine compatible |
| Network / Transport Protocol |
TCP/IP, AppleTalk, PPPoE, iSCSI, LPR/LPD, FTP |
| Data Link Protocol |
10 Gigabit Ethernet |
| Network Services Compatibility |
Microsoft Active Directory (AD), DDNS, Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV) |
| Compliant Standards |
DLNA CERTIFIED, UPnP |
| Dimensions & Weight |
|
| Height |
6.9in |
| Width |
19in |
| Depth |
40.2in |
| Weight |
83.55lbs |
| Service & Support |
|
| Type |
5-year warranty |
| Hard Drive |
|
| Capacity |
480GB |
| Type |
SSD |
| Installed Qty |
2 |
| Hot-Swap |
Hot-swap |
| Processor / Memory |
|
| Max Supported Qty |
2 |
| RAM |
64 GB (installed) / 512 GB (supported) - DDR4 |
| Processors Installed |
2 x Xeon Silver 4210R 2.4 GHz |
| Max Turbo Speed |
3.2 GHz |
| Features |
ECC |
| Number of Cores |
10-core |
| Storage |
|
| Network Storage Type |
NAS server |
| iSCSI support |
iSCSI |
| Rack-mountable |
Rack-mountable |
| Total Storage Capacity |
960GB |
| Header |
|
| Model |
HD6500 |
| Product Line |
Synology High Density |
| Packaged Quantity |
1 |
| Storage Controller |
|
| RAID Level |
RAID 5 hot spare |
| Type |
RAID |
| Interface Type |
Serial ATA-600 |
| Manufacturer Warranty |
|
| Service & Support |
Limited warranty - 5 years |
| Environmental Parameters |
|
| Min Operating Temperature |
32 °F |
| Max Operating Temperature |
95 °F |
| Sound Emission |
60.8 dBA |
| Humidity Range Operating |
5 - 95% |
| General |
|
| Total Storage Capacity |
960 GB |
| Depth |
40.2 in |
| Host Connectivity |
Gigabit Ethernet / 10 Gigabit Ethernet |
| Installed Devices / Modules Qty |
2 (installed) / 60 (max) |
| Width |
19 in |
| Weight |
83.55 lbs () |
| Device Type |
NAS server |
| Enclosure Type |
Rack-mountable - 4U |
| Height |
6.9 in |
| Power |
|
| Voltage Required |
AC 200-240 V |
| Power Device |
Internal power supply |
| Power Provided |
1600 watt |
