| Processor / Performance |
|
| Processor |
Intel® Core™ i7-1370PRE P-Series, 6 P-cores 1.9GHz up to 4.8GHz and 8 E-cores 1.2GHz up to 3.7GHz |
| Intel® Smart Cache |
24MB |
| Memory / Storage |
|
| Memory |
Dual channel LPDDR5x 6000 MT/s SDRAM (memory soldered down), 64GB |
| Onboard NVMe SSD |
128GB |
| Industrial Grade NVMe SSD |
M.2 (1TB included), up to 2TB available, 960GB |
| Additional Storage |
M.2 2280 Key M socket (PCIe x4) for additional NVMe Drive |
| CFast Socket |
2 × CFast socket with latching retainer |
| Features |
|
| Real Time Clock |
PC compatible with Goldcap backup (up to 48h) |
| Hardware Watchdog & Temperature Supervisor |
Battery option on request |
| TPM |
TPM 2.0 according to ISO/IEC11889 |
| UEFI Secure Boot |
Key material must be provided by customer, custom BIOS version required (on request) |
| Inertial Measurement Unit |
STMicroelectronics ISM330DHCX (Please see Product Manual for more detailed information and maximum sampling rate) |
| Buzzer |
Special driver required |
| Power |
Ignition Controller |
| Communication Interfaces |
|
| DisplayPort |
1 × DisplayPort 1.4a |
| USB |
4 × USB 3.2 (5Gbps) Type-A |
| Ethernet |
4 × 100/1000/2500Mbit Ethernet (NBASE-T) with separated Intel® I226-IT NIC's (M12 female X-coded) |
| CAN |
2 × CAN 2.0A/B & CAN FD (PEAK FPGA chip), active/passive, isolated, expandable to max.
6 × CAN-FD (DSUB)
|
| Serial RS232 |
1 × RS232 RX, TX, RTS, CTS, GND (DSUB) |
| Serial RS422/485 |
RX, TX, RTS, CTS, GND – Galvanic isolation (DSUB) (on request) |
| Digital I/O |
24/36VDC – Galvanic isolation 1500Vrms (process to Logic), 2×5-pin Terminal Block, current sourcing output/current sinking inputs, 4 inputs, 4 outputs |
| Analog Input Module |
Voltage and Current version available (on request) |
| M.2 Sockets |
1 × M.2 Key E (2230) and 1 × M.2 Key B (3042/3052) socket |
| Mini PCIe |
1 × Mini PCIe socket |
| Wireless Connectivity |
|
| Global 5G RedCap |
Telit FN920C04-WW–DVT (2 × SMA), Dual nano SIM support: n/a |
| Global 5G (4G Fallback) |
Sierra Wireless EM9291 – M2M only! (4 × SMA), Dual nano SIM support (on request) |
| High Precision GNSS |
u-blox ZED-F9R6 with RTK and dead reckoning (1 × SMA), n/a |
| Wireless LAN |
Wi-Fi 6 (802.11ac/a/b/g/n/ax), Intel Wireless-AX210, Bluetooth 5.2 Module (2 × RP-SMA), n/a |
| Technical Data |
|
| Dimensions |
314 × 99 × 170 mm (housing incl. mounting plate) |
| Net Weight |
~3200 g |
| Input Voltage |
16.8 ... 137.5VDC, isolated and reverse polarity protected (M12 male K-coded/Push Pull) |
| Voltage Supply Interruption |
EN50155 Class S2, 10ms |
| Power Consumption |
Typical 30–40W @ 24V without Add-Ins |
| Environmental Conditions |
|
| Operating Temperature |
–40°C ... +70°C (complies with EN50155 Class OT4/ST0) |
| Storage Temperature |
–40°C ... +85°C (Recommended storage temperature 20°C ... 25°C) |
| Ingress Protection |
IP40 according to EN60529 |
| Conformal Coating |
PCX |
| MTBF |
According to Telcordia SR-332, Environment GM, excluding CFast and optional interfaces (TBD) |
| Certifications |
|
| Railway Certification |
EN50155 |
| Railway Environmental Conditions |
EN50125 |
| Shock & Vibration |
EN60068-2-27 / EN60068-2-64 / EN61373 |
| EMI Conformity |
EN50121-3-2 / EN301489-1 |
| Safety |
Designed to meet EN62368-1 |
| Fire Protection |
DIN EN45545-2 HL3 |
| e-Mark |
On request |
| Compliance |
CE/UKCA, UN/ECE R10 |
| Software |
|
| Operating Systems |
Linux Debian 12 (Bookworm), Windows 11 IoT Enterprise LTSC 2024, Ubuntu Pro LTS |
