| Mobile |
|
| Mobile module |
5G Sub-6Ghz SA/NSA 2.4/3.4Gbps DL (4x4 MIMO), 900/550 Mbps UL (2x2); 4G (LTE) –
LTE Cat 19 1.6Gbps DL, Cat 18 200Mbps UL; 3G – 42 Mbps DL, 5.76Mbps UL
|
| 3GPP Release |
Release 16 |
| eSIM |
Consumer type eSIM, profile download and removal operations, up to 7 eSIM profiles; does
not include data plans
|
| SIM switch |
2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network,
network denied, data connection fail, SIM idle protection
|
| Status |
IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, c
onnected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received,
LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNC
|
| SMS |
SMS status, SMS configuration, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS,
scheduled SMS, SMS autoreply, SMPP
|
| USSD |
Supports sending and reading Unstructured Supplementary Service Data messages |
| Block/Allow list |
Operator block/allow list (by country or separate operators) |
| Band management |
Band lock, Used band status display |
| SIM idle protection service |
Provides the possibility to configure the router to periodically switch to the unused SIM
card and establish a data connection in order to prevent the SIM card from being blocked
|
| SIM PIN code management |
SIM PIN code management enables setting, changing, or disabling the SIM card's PIN |
| APN |
Auto APN |
| Bridge |
Direct connection (bridge) between mobile ISP and device on LAN |
| Passthrough |
Router assigns its mobile WAN IP address to another device on LAN |
| Framed routing |
Framed routing: support an IP network behind 5G UE |
| Ethernet |
|
| Ethernet |
2 x ETH ports (can be configured as WAN), 10/100/1000 Mbps, compliance with IEEE 802.3,
IEEE 802.3u, IEEE 802.3az standards, supports auto MDI/MDIX crossover
|
| POE IN |
|
| PoE ports |
1 x PoE In |
| PoE standards |
802.3af/at |
| POE OUT |
|
| PoE ports |
1 x PoE Out |
| PoE standards |
802.3af Alternative B |
| PoE Max Power per Port (at PSE) |
15 W Max (power supply unit dependent) |
| Network |
|
| Routing |
Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing |
| Network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP,
VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL),
VXLAN
|
| VoIP passthrough support |
H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
| Connection monitoring |
Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
| Firewall |
Port forward, traffic rules, custom rules, TTL target customisation |
| Firewall status page |
View all your Firewall statistics, rules, and rule counters |
| Port management |
View device ports, enable and disable each of them, turn auto-configuration on or off,
change their transmission speed, and so on
|
| Network topology |
Visual representation of your network, showing which devices are connected to which other devices |
| DHCP |
Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases:
MAC with wildcards
|
| QoS / Smart Queue Management (SQM) |
Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e |
| DDNS |
Supported >77 service providers, others can be configured manually |
| DNS over HTTPS |
DNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPS |
| Network backup |
VRRP, Wired options, each of which can be used as an automatic Failover |
| Load balancing |
Balance Internet traffic over multiple WAN connections |
| SSHFS |
Possibility to mount remote file system via SSH protocol |
| VRF support |
Initial virtual routing and forwarding (VRF) support |
| Traffic Management |
Real-time monitoring, wireless signal charts, traffic usage history |
| Security |
|
| Authentication |
Pre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS
users authentication, IP & login attempts block, time-based login blocking, built-in random
password generator
|
| Firewall |
Preconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI,
DMZ, NAT, NAT-T, NAT64
|
| Attack prevention |
DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention),
port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
|
| VLAN |
Port and tag-based VLAN separation |
| Mobile quota control |
Mobile data limit, customizable period, start time, warning limit, phone number |
| WEB filter |
Block list for blocking out unwanted websites, allow list for specifying allowed sites only |
| Access control |
Flexible access control of SSH, Web interface, CLI and Telnet |
| TPM |
Identification and authentication module, TPM 2.0 standard |
| Certificate Manager |
Certificate creation tool allows to create CA, server, client, let's encrypt, SCEP certificates |
| 802.1x |
Port-based network access control server |
| VPN |
|
| OpenVPN |
Multiple clients and a server can run simultaneously, 27 encryption methods |
| IPsec |
XFRM, IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16) |
| GRE |
GRE tunnel, GRE tunnel over IPsec support |
| PPTP, L2TP |
Client/Server instances can run simultaneously, L2TPv3, L2TP over IPsec support |
| Stunnel |
Proxy designed to add TLS encryption functionality to existing clients and servers without any
changes in the program’s code
|
| DMVPN |
Method of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub support |
| SSTP |
SSTP client instance support |
| ZeroTier |
ZeroTier VPN client support |
| WireGuard |
WireGuard VPN client and server support |
| Tinc |
Tinc offers encryption, authentication and compression in it's tunnels. Client and server support. |
| Tailscale |
Tailscale offers speed, stability, and simplicity over traditional VPNs.
Encrypted point-to-point connections using the open source WireGuard protocol
|
| BacNET |
|
| Supported modes |
Router |
| Supported connection types |
IP |
| OPC UA |
|
| Supported modes |
Client, Server |
| Supported connection types |
TCP |
| MODBUS |
|
| Supported modes |
Server, Client |
| Supported connection types |
TCP |
| Custom registers |
MODBUS TCP custom register block requests, which read/write to a file inside the router,
and can be used to extend MODBUS TCP Client functionality
|
| Supported data formats |
8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian),
DCBA (little-endian), CDAB, BADC), HEX, ASCII
|
| Data to Server |
|
| Protocol |
HTTP(S), MQTT, Azure MQTT |
| Data to server |
Extract parameters from multiple sources and different protocols, and send them all to a single
server; Custom LUA scripting, allowing scripts to utilize the router's Data to server feature
|
| MQTT Gateway |
|
| Modbus MQTT Gateway |
Allows sending commands and receiving data from MODBUS Server through MQTT broker |
| DNP3 |
|
| Supported modes |
Station, Outstation |
| Supported connection |
TCP |
| DLMS/COSEM |
|
| DLMS Support |
DLMS - standard protocol for utility meter data exchange |
| Supported modes |
Client |
| Supported connection types |
TCP |
| System Characteristics |
|
| CPU |
MediaTek, Dual-core, 880 MHz, MIPS1004Kc |
| RAM |
256 MB, DDR3 |
| FLASH storage |
16 MB serial NOR flash, 256 MB serial NAND flash |
| Firmware/Configuration |
|
| WEB UI |
Update FW from file, check FW on server, configuration profiles, configuration backup |
| FOTA |
Update FW |
| RMS |
Update FW/configuration for multiple devices at once |
| Keep settings |
Update FW without losing current configuration |
| Factory settings reset |
A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration |
| FIRMWARE CUSTOMISATION |
|
| Operating system |
RutOS (OpenWrt based Linux OS) |
| Supported languages |
Busybox shell, Lua, C, C++, and Python, Java in Package manager |
| Development tools |
SDK package with build environment provided |
| GPL customization |
You can create your own custom, branded firmware and web page application by changing
colours, logos, and other elements in our firmware to fit your or your clients’ needs
|
| Package Manager |
The Package Manager is a service used to install additional software on the device |
| Power |
|
| Connector |
RJ45 Socket |
| Input voltage range |
42.5–57.0 VDC, reverse polarity protection, voltage surge/transient protection |
| Input voltage range for PoE |
42.5–57.0 VDC, reverse polarity protection, voltage surge/transient protection |
| Power consumption |
Idle: < 2.5 W / Max: < 9 W / PoE Max < 24 W |
| Physical Interfaces |
|
| Ethernet |
2 x RJ45 ports, 10/100/1000 Mbps |
| Status LEDs |
3 x Mobile connection type, 3 x Mobile connection strength, 4 x ETH status LEDs |
| SIM |
2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V |
| Power |
RJ45, PoE In, 42.5 – 57.0 VDC |
| Antennas |
4 x internal antennas |
| Antennas specifications |
4 x 617 - 960 / 1695 - 2690 / 3300 - 4200 / 4200 - 5000MHz, 50 Ω, VSWR <3.5, gain
<4.9 dBi, omnidirectional
|
| Reset |
Reboot/User default reset/Factory reset button |
| Physical Specification |
|
| Casing material |
Plastic (PC+ASA) |
| Dimensions (W x H x D) |
110 x 49.30 x 235 mm |
| Weight |
385 g |
| Mounting options |
Mounting bracket (for vertical flat surface or pole mounting) |
| Operating Environment |
|
| Operating temperature |
-40 °C to 55 °C |
| Operating humidity |
10% to 90% non-condensing |
| Ingress Protection Rating |
IP55 |
| Regulatory & Type Approvals |
|
| Regulatory |
CE, UKCA, RCM, CB, EAC, UCRF, WEEE |
