| Working Modes |
Range Extender/Access Point |
| Interface |
1 Gigabit Ethernet Port |
| Button |
WPS Button, Reset Button |
| Input Power |
100-240V~50/60Hz |
| Max. Power Consumption |
10W |
| Dimensions ( W x D x H ) |
3.1×1.4×5.9 in. (78×36×149 mm) |
| Antenna |
2 Internal Antennas |
| Wireless Standards |
IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n 2.4GHz |
| Frequency |
2.4GHz and 5GHz |
| Signal Rate |
300 Mbps at 2.4GHz, 1200 Mbps at 5GHz |
| Reception Sensitivity 5GHz |
11a 6Mbps: -93dBm,
11a 54Mbps: -75dBm,
11ac HT20 MCS0: -92dBm,
11ac HT20 MCS8: -70dBm,
11ac HT40 MCS0: -90dBm,
11ac HT40 MCS9: -66dBm,
11ac HT80 MCS0: -87dBm,
11ac HT80 MCS9: -62dBm
|
| Reception Sensitivity 2.4GHz |
11g 54Mbps: -77dBm,
11n HT20 MCS7: -75dBm,
11n HT40 MCS7: -72dBm
|
| Wireless Functions |
Enable/Disable Wireless Radio,
DFS (the latest firmware and hardware version is required),
Access Control, LED Control, Power Schedule, Wi-Fi Coverage
|
| Wireless Security |
64/128-bit WEP, WPA/WPA2-PSK encryptions |
| Transmission Power |
CE: 2.4GHz ≤20dBm, 5GHz ≤30dBm |
| Certification |
FCC, RoHS |
| Package Content |
Wi-Fi Range Extender RE500X, Quick Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8,
8.1, 10, MAC OS, NetWare, UNIX or Linux; Internet Explorer 11,
Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
|
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉),
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing,
Storage Humidity: 5%~90% non-condensing
|
