| Wireless Standards & Protocols |
Wi-Fi 6, IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2.4 GHz |
| WiFi Speeds |
AX6600: 5 GHz: 4804 Mbps (802.11ax, HE160)
5 GHz: 1201 Mbps (802.11ax)
2.4 GHz: 574 Mbps (802.11ax)
|
| WiFi Range |
4 Bedroom Houses,
8× Detachable High-Performance Antennas
Beamforming, High-Power FEM, 4T4R
|
| WiFi Capacity |
Very High, Tri-Band, 4×4 MU-MIMO, OFDMA, Airtime Fairness, DFS, 8 Streams |
| Working Modes |
Router Mode, Access Point Mode |
| Network Security |
SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway |
| HomeCare™ Security |
Antivirus, Malicious Site Checker, Port Intrusion Prevention
Infected Device Isolation, Notification and Log
|
| Guest Network |
2× 5 GHz Guest Network, 1× 2.4 GHz Guest Network |
| VPN Server |
OpenVPN, PPTP |
| VPN Client |
OpenVPN Client, PPTP VPN Client, L2TP VPN Client |
| WiFi Encryption |
WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x) |
| Processor |
1.5 GHz Quad-Core CPU |
| Ethernet Ports |
1× 2.5 Gbps WAN/LAN Port
1× Gigabit WAN/LAN Port
3× Gigabit LAN Ports
|
| USB Support |
1× USB 3.0 Port, 1× USB 2.0 Port,
Supported Formats: NTFS, exFAT, HFS+, FAT32,
Functions: Apple Time Machine, FTP Server, Media Server, Samba Server
|
| Buttons |
Wi-Fi On/Off, Power On/Off, LED On/Off, WPS, Reset |
| Power |
12 V ⎓ 5 A |
| Protocols |
IPv4, IPv6 |
| Game Center |
Game Accelerator, Game Statistics, Game Protector |
| Service Kits |
HomeCare™, OneMesh™ Supported |
| Parental Controls |
HomeCare™ Parental Controls, Custom Profiles,
Content Filtering, App Block, URL Filtering, Time Limit,
Time Schedule (Bedtime), Log Insight
|
| WAN Types |
Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
| Quality of Service |
Game Accelerator QoS, QoS by Device, HomeCare™ QoS, QoS by Application |
| Cloud Service |
Auto Firmware Upgrade, OTA Firmware Upgrade, TP-Link ID, DDNS |
| NAT Forwarding |
Port Forwarding, Port Triggering, DMZ, UPnP |
| IPTV |
IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN |
| DHCP |
Address Reservation, DHCP Client List, Server |
| DDNS |
TP-Link, NO-IP, DynDNS |
| System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+,
or other JavaScript-enabled browser; Cable or DSL Modem (if needed);
Subscription with an internet service provider
|
| Certifications |
FCC, CE, RoHS |
| Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉),
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing,
Storage Humidity: 5%~90% non-condensing
|
