| Management features |
| MIB support |
RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925 |
| System event log |
Yes |
| ARP inspection |
Yes |
| Configuring Location Settings (CLI) |
Yes |
| Unified static configuration |
Yes |
| Cloud-managed |
Yes |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2+ |
| Switch type |
Managed |
| Ports & interfaces |
| Console port |
RJ-45/USB Type-C |
| Installed SFP+ modules quantity |
8 |
| 10G Ethernet (copper) ports quantity |
24 |
| 2.5G Ethernet (copper) ports quantity |
24 |
| Gigabit Ethernet (copper) ports quantity |
24 |
| Fast Ethernet (copper) ports quantity |
24 |
| Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Network |
| Number of VLANs |
4000 |
| Virtual LAN features |
MVRP, Private VLAN, SSID-based VLAN assignment, VLAN Identifier ( VLAN ID), Voice VLAN |
| VLAN support |
Yes |
| Address Resolution Protocol (ARP) entries (max) |
510 |
| Auto MDI/MDI-X |
Yes |
| Auto-negotiation |
Yes |
| Broadcast storm control |
Yes |
| Ethernet Ring Protection Switching (ERPS) |
Yes |
| IPv4 routes |
48 |
| IPv6 routes |
48 |
| Link aggregation |
Yes |
| Rate limiting |
Yes |
| Spanning tree protocol |
Yes |
| Port mirroring |
Yes |
| 10G support |
Yes |
| Networking standards |
IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1af, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3x |
| Data transmission |
| Packet buffer memory |
24 MB |
| Jumbo frames |
9 |
| Jumbo frames support |
Yes |
| Static route |
Yes |
| Number of queues |
8 |
| Forwarding rate |
240 Mpps |
| Switching capacity |
640 Gbit/s |
| MAC address table |
32000 entries |
| Security |
| Authentication |
Guest VLAN |
| Authentication type |
AAA, RADIUS, TACACS+ |
| CPU defense |
Yes |
| DoS attack prevention |
Yes |
| Queue scheduling algorithms |
Strict Priority Queue (SPQ), WRR+SP, Weighted Round Robin (WRR) |
| Security algorithms |
HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSL/TLS |
| Static port security |
Yes |
| IGMP snooping |
Yes |
| Access Control List (ACL) |
Yes |
| DHCP features |
DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| Multicast features |
| Multicast Listener Discovery (MLD) snooping |
Yes |
| Multicast support |
Yes |
| Protocols |
| IPv4 & IPv6 features |
Dual stack IPv4/IPv6, IPv6 SNMP, IPv6 SSH, IPv6 TFTP, IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Device link detection protocol (DLDP) |
Yes |
| Design |
| Number of fans |
4 fan(s) |
| LED indicators |
Yes |
| Housing material |
Metal |
| Product colour |
Black |
| Form factor |
DIN rail |
| Stackable |
Yes |
| Rack mounting |
Yes |
| Performance |
| Minimum system requirements |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Fanless |
No |
| Firmware upgradeable |
Yes |
| Power |
| Power saving mode (EEE) |
Yes |
| Power consumption (max) |
1010.2 W |
| Power consumption (typical) |
953.7 W |
| AC input frequency |
50/60 Hz |
| AC input voltage |
110 - 240 V |
| Power supply included |
No |
| Power source |
AC/PoE |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
770 W |
| Power over Ethernet (PoE) power per port |
90 W |
| Power over Ethernet 4PPoE (PoE++) ports quantity |
24 |
| Power over Ethernet (PoE) |
Yes |
| Other features |
| Packaging content |
Console Cable |
| Operational conditions |
| Heat dissipation |
3444.7 BTU/h |
| Operating temperature (T-T) |
-5 - 45 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating temperature (T-T) |
-5 - 45 °C |
| Weight & dimensions |
| Height |
44 mm |
| Depth |
330 mm |
| Width |
440 mm |
| Packaging content |
| Rack mount kit |
Yes |
| Quick start guide |
Yes |
| Cables included |
Power |
| Packaging data |
| Mounting brackets included |
Yes |
| Rubber feet |
Yes |
| Screws included |
Yes |
| Sustainability |
| Sustainability organizations |
Accountability |
| Certificates |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
