8-Port Unmanaged 2.5G Switch
Expand your network’s bandwidth and reduce digital bottlenecks with TRENDnet’s Unmanaged 2.5G Switches. These 2.5G network switches come equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. Each high-speed 2.5G switch features a durable metal enclosure and can be mounted to the wall for setup flexibility. The fanless design lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 2.5G switches are cost-effective solutions to increase your network’s throughput.
2.5G Ports
Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling.
Wall Mountable
The 2.5G switches feature metal housing with a convenient wall mountable design for greater installation flexibility.
Fanless
The fanless design of the 2.5G switches lowers energy consumption costs and eliminates operating noise.
Easy Installation
No configuration needed, simply connect network devices to the 2.5G Ethernet switch
2.5G Ports
Equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling
Fanless
Fanless design lowers energy consumption and eliminates operating noise
Housing Design
Sturdy metal housing
Wall Mountable
Features a convenient wall mountable design for greater installation flexibility
Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 12KB) for increased performance
LED Indicators
LED indicators on this 2.5G switch conveys port status
Specifications
| Management features |
| Switch type |
Unmanaged |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Network |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Full duplex |
Yes |
| Half duplex |
Yes |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Data transmission |
| Jumbo frames |
12000 |
| Jumbo frames support |
Yes |
| Forwarding rate |
29.76 Mpps |
| Switching capacity |
40 Gbit/s |
| MAC address table |
16000 entries |
| Design |
| Wall mountable |
Yes |
| LED indicators |
Yes |
| Housing material |
Metal |
| Product colour |
Black |
| Performance |
| Mean time between failures (MTBF) |
1401356 h |
| Power |
| Power consumption (max) |
12.4 W |
| Input current |
1.5 A |
| DC input voltage |
12 V |
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
100 - 240 V |
| Power supply included |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
| Weight |
600 g |
| Height |
26 mm |
| Depth |
103 mm |
| Width |
240 mm |
| Packaging content |
| Quick start guide |
Yes |
| Certificates |
| Certification |
FCC, CE |
