V.SOL V2802RH XPON Dual Mode FTTO Optical Network Terminal (ONT)

V.SOL V2802RH XPON Dual Mode FTTO Optical Network Terminal (ONT)

V.SOL V2802RH is an XPON Dual Mode FTTO Optical Network Terminal designed for flexible fiber access deployments in Fiber to the Office environments. It supports both EPON and GPON technologies, allowing automatic access to compatible EPON or GPON OLT networks through a single XPON port.

The V2802RH features 1 × 2.5GbE and an optional 1 × GE interface with auto-negotiation and RJ45 connectivity. This combination provides flexible wired networking for FTTO deployments, while its compact 100 × 92 × 29.5 mm form factor helps simplify installation where space is limited.

Its XPON interface supports EPON PX20+ and GPON Class B+ with an SC/UPC single-mode connector and a transmission distance of up to 20km. The dual-mode functionality allows the ONT to automatically access EPON or GPON OLT infrastructure, providing greater flexibility for different optical access networks.

The V.SOL V2802RH supports bridging and routing modes for adaptable network deployment. Its hardware design includes abnormal protection functions such as rogue ONU detection and hardware dying gasp, helping provide operational monitoring and protection within FTTO access environments.

Designed for practical fiber network installations, the V2802RH operates from −10°C to +55°C with 5–95% non-condensing humidity. Its external DC 12V, 0.5A power adapter, compact enclosure, and status indicators for POWER, PON, LOS, WAN, LAN1, and LAN2 support straightforward deployment and monitoring.

Key Features

• XPON dual-mode FTTO Optical Network Terminal

• Automatic EPON/GPON OLT access

• EPON PX20+ and GPON Class B+ support

• 20km optical transmission distance

• 1 × 2.5GbE interface

• 1 × optional GE interface

• Bridging and routing mode support

• Rogue ONU detection and hardware dying gasp

Specifications:
