Westermo L108-F2G-S2-12VDC Industrial 12V Layer 2 Managed Switch

Industrial networks often need more than Ethernet alone, especially when legacy serial equipment, digital I/O, and different network segments have to operate together in a compact installation. The Westermo L108-F2G-S2-12VDC combines Layer 2 managed Ethernet switching with serial communication, SFP connectivity, USB, and digital I/O, making it suitable for industrial systems that require several communication interfaces in one device.

Westermo L108-F2G-S2-12VDC Industrial 12V Layer 2 Managed Switch

The Westermo L108-F2G-S2-12VDC is an industrial Layer 2 Device Server Switch designed to connect Ethernet equipment while also supporting serial devices. It provides four 100 Mbit/s TX ports and two Gbit SFP ports, allowing standard Ethernet equipment to be connected alongside higher-speed fiber network interfaces. The Layer 2 software architecture is supported by Westermo's WeOS software.

A major benefit of this switch is its combination of network and serial connectivity. Two serial ports are available for equipment that communicates through serial interfaces, while USB, one digital input, and one digital output provide additional interfaces for system integration. This makes the switch useful where industrial equipment uses a mixture of Ethernet and serial communication rather than Ethernet alone.

The L108-F2G-S2-12VDC is built for industrial installations where equipment may experience wide temperature changes and challenging environmental conditions. It operates from -40 to +70°C and supports storage and transport temperatures from -50 to +85°C. The IP40 protection and full-metal housing provide a robust enclosure for installation in industrial and infrastructure environments.

Its compact 52 x 100 x 101 mm dimensions allow it to fit into space-constrained network installations, while the zinc fire enclosure provides the specified enclosure construction. The switch also supports operation at an altitude of 2000 m/80 kPa and 5-95% relative humidity, with IEC 60068-2-60 corrosive gas compliance.

The L108-F2G-S2-12VDC is suited to industrial automation, railway signalling and telecommunications, transportation infrastructure, marine systems, and other applications where managed Layer 2 networking must work alongside serial and digital interfaces. Its trackside, environmental, safety, and marine approvals further support deployment in demanding infrastructure applications.

Key features

• Industrial Layer 2 Device Server Switch
• 4 x 100 Mbit/s TX ports
• 2 x Gbit SFP ports
• 2 serial ports for serial communication
• 1 USB interface
• 1 digital input and 1 digital output
• WeOS software with L2 software layer
• -40 to +70°C operating temperature

Specifications:
