Western Digital Ultrastar DC HC590, 26TB 3.5" SAS 12Gb/s Data Center Hard Drive
Western Digital 24TB internal hard drive is designed for high-capacity storage in demanding data environments. It features a 3.5-inch form factor, 7200 RPM spindle speed, and Serial Attached SCSI 3 interface with SAS 12 Gb/s connectivity for enterprise-class storage applications.
The drive provides a 24TB storage capacity with a 512MB buffer and a maximum internal data transfer rate of 287 MBps. It uses Conventional Magnetic Recording (CMR), Energy-Assisted Magnetic Recording (EAMR), HelioSeal, and OptiNAND technology to support high-capacity storage and consistent performance.
Built for continuous operation, the hard drive supports 24x7 availability and includes features such as ArmorCache Technology, Dynamic Fly Height Technology, and Rotational Vibration Safeguard (RVS). It also offers a 2,500,000-hour MTBF and a non-recoverable error rate of 1 per 10^15.
The drive also provides hardware encryption with Self-Encrypting Drive (SED) functionality. With a 5-year limited warranty, 600,000 load/unload cycles, and support for 3.5-inch drive bays, it is suited for compatible enterprise storage systems requiring high capacity and reliable continuous operation.
Key Features
-
24TB high-capacity internal hard drive
-
3.5-inch form factor with 7200 RPM spindle speed
-
SAS 12 Gb/s interface with Serial Attached SCSI 3
-
512MB buffer size and 287 MBps maximum internal data transfer rate
-
Supports 24x7 continuous operation
-
CMR, EAMR, HelioSeal and OptiNAND technologies
-
2,500,000-hour MTBF with 1 per 10^15 non-recoverable errors
-
Self-Encrypting Drive with hardware encryption
Specifications
| Storage |
|
| Average Latency |
4.16 millisecond |
| Buffer Size |
512 megabyte |
| Data Transfer Rate (Hard Drive) |
1.2 GBps |
| Form Factor (Short) |
3.5" |
| Form Factor (Short) (metric) |
8.9 cm |
| Hard Drive Capacity |
24 TB |
| Hard Drive Type |
Internal hard drive |
| HD Interface |
Serial Attached SCSI 3 |
| Load/Unload Cycles |
600,000 |
| Max Internal Data Transfer Rate |
287 MBps |
| Non-Recoverable Errors |
1 per 10^15 |
| Spindle Speed (rpm) |
7200 revolutions per minute |
| Storage Interface |
Serial Attached SCSI 3 |
| 24x7 Operation |
Yes |
| Connectivity |
|
| Interface Provided |
1 x SAS 12 Gb/s |
| Display & Graphics |
|
| Touchscreen |
No |
| Power |
|
| Power Consumption |
5.9 watt (idle), 8.7 watt (random read/write) |
| Technical Information |
|
| Compatible Bay |
3.5" |
| Hard Drive Form Factor |
3.5" |
| Hard Drive Form Factor (metric) |
8.9 cm |
| Max Operating Temperature |
140 degree Fahrenheit |
| Max Storage Temperature |
158 degree Fahrenheit |
| Min Operating Temperature |
41 degree Fahrenheit |
| Min Storage Temperature |
-40 degree Fahrenheit |
| MTBF |
2,500,000 Hours |
| Shock Acceleration (Non-operating) |
200 gram |
| Shock Acceleration (Operating) |
40 gram |
| Shock Duration (Non-operating) |
Half-sine wave |
| Shock Duration (Operating) |
2 ms half-sine wave |
| Vibration Acceleration (Non-operating) |
1.04 gRMS |
| Vibration Acceleration (Operating) |
0.7 gRMS |
| Vibration Frequency Range (Non-operating) |
2-200 Hz |
| Vibration Frequency Range (Operating) |
5-500 Hz |
| Product Information |
|
| Encryption Details |
Self-Encrypting Drive (SED) |
| Hardware Encryption |
Yes |
| Packaged Quantity |
1 |
| Product Type |
Hard Drive |
| Service Activation |
No |
| Dimensions & Weight |
|
| Height |
1 inch |
| Weight |
23.63 ounce |
| Width |
4 inch |
| Depth |
5.8 inch |
| Certifications & Listings |
|
| ENERGY STAR Certified |
No |
| EPEAT Compliant |
No |
| TCO Certified |
No |
