15 Inch Dual Ethernet Advanced HMI Panel with CODESYS Support
15 Inch Dual Ethernet Advanced HMI Panel with CODESYS Support
15 inch dual Ethernet advanced HMI panel display with touchscreen interface
advanced HMI with CODESYS showing dual LAN ports and aluminum housing
15 inch HMI panel front view with resistive touch and LCD display
industrial advanced HMI rear ports including Ethernet USB and serial connections

Maple Systems Inc. 15 Inch Dual Ethernet Advanced HMI Panel with CODESYS Support

UK Free Shipping UK Free Shipping over £249

Buy 5 or More Units - Unlock Priority Discounts!
Buy 20 or More Units - Get Exclusive Volume Discounts!


Also Support: Google & Apple Pay

Are you a reseller or placing a large order?
We're happy to offer Special Pricing tailored to your needs.
Click "Request Quote" or email us at [email protected] to get your best price today!

Add to Wishlist

Compare

Product Code: PNLP-032

MPN #: cMT2158Xv2-CODESYS

Tired of slow, unreliable control screens that freeze during critical operations? The 15 Inch Dual Ethernet Advanced HMI Panel with CODESYS Support gives you a fast, rugged interface that keeps your machines running smoothly. It is built for industrial automation, letting you monitor and control processes from a clear, touch-enabled display. If your current panel drops connections or lacks the power to run complex graphics, you need a reliable solution now.



Maple Systems Inc. 15 Inch Dual Ethernet Advanced HMI Panel with CODESYS Support

Many factories struggle with a single network link that becomes a bottleneck when data traffic spikes. Without enough CPU power, the screen cannot render real-time charts, causing delays. This panel solves both issues by offering two Ethernet ports - a 10/100 LAN and a Gigabit LAN - and a quad-core RISC CPU with 1 GB RAM. The built-in CODESYS support lets you program directly on the device, removing the need for extra controllers. The result is a stable, fast, and easy-to-manage HMI that fits into any modern automation line.





Specifications
Category Parameter Specification
System CPU Quad-Core RISC
  Memory (RAM) 1 GB
  Memory (Flash) 4 GB
  RTC Built-in
  Programming Software EBPro (Latest Version)
I/O Ports Ethernet/LAN LAN 1: 10/100 Base-T RJ-45; LAN 2: GbE RJ-45
  CANbus N/A
  Audio Output 1x Line Out / Built-in Mono Speaker
  SD Card Slot SD/SDHC (32GB capacity)
  USB Host Ports USB 2.0 x 1
  USB Client Ports N/A
  Wi-Fi N/A
  COM Port 1 x DE9S COM1: RS-485 2 or 4 wire, COM3: RS-485 2 wires
  COM Port (cont.) 1 x DE9P COM1: RS-232, COM3: RS-232
  RS-485 Dual Isolation Yes
  Local bus N/A
  HDMI Port N/A
  Video Input N/A
  Serial Ports 2
Display Display Size 15" WVA LCD
  Resolution 1024 X 768
  Luminance (cd/m^2) 350
  Contrast Ratio 2500:1
  Backlight Type LED
  Backlight Lifetime (hrs) 70,000+
  Colors 16.2 M
  Display Type 15" WVA LCD
  Viewing Angle (H°/V°) 176/176
  Size (W x H) 12.00 x 9.00 inches [304.7 x 228.5 mm]
Touch Screen Type 4-wire resistive touch
  Accuracy Length (x)±2%, Width(y)±2%
  Touch Panel Hardness Scale N/A
Electrical Input Power 31.2 W
  Power Isolation Built-in
  Power Dissipation N/A
  Current for Internal Bus N/A
  Current Consumption N/A
  Isolation Resistance Exceed 50 MO – @ 500 VDC
  Input Voltage 24 ± 20% VDC
  Input Current 1.3 A @ 24 VDC
Mechanical Vibration Endurance 10 to 25 Hz (X, Y, Z direction, 2G, 30 minutes)
  Enclosure Material Aluminum, charcoal grey
  PCB Coating Yes
  Dimensions WxHxD 14.41 x 11.54 x 1.9 inches [366 x 293 x 48.2 mm]
  Panel Cutout (inches) [mm] 13.86 x 10.98 [352 x 279]
  Weight Approx. 5.73 lbs. [2.6 kg]
  Mounting Panel mount, VESA 75 x 75 mm
Environmental Operating Temperature 32° ~ 122°F (0° ~ 50°C)
  Storage Temperature -4° ~ 140°F (-20° ~ 60°C)
  Relative Humidity 10% ~ 90% (non-condensing)
Certification CE UKCA Yes
  UL Type Rating UL Class 1 Div 2 / UL Type 4X (indoor use only)
  NEMA Rating NEMA4
  IP Rating IP66 Compliant Front Panel
  CE Yes
  UL cULus Listed
  Class 1 Div 2 Yes
  ATEX N/A
  RoHS Yes
