Advantech ARK-1125H, Intel® Processor N-series N200, DDR5 4800 MHz Embedded PC
Advantech ARK-1125H, Intel® Processor N-series N200, DDR5 4800 MHz Embedded PC
Advantech ARK-1125H, Intel® Processor N-series N200, DDR5 4800 MHz Embedded PC
Advantech ARK-1125H, Intel® Processor N-series N200, DDR5 4800 MHz Embedded PC
Advantech ARK-1125H, Intel® Processor N-series N200, DDR5 4800 MHz Embedded PC
Logo

Advantech ARK-1125H, Intel® Processor N-series N200, DDR5 4800 MHz Embedded PC

UK Free Shipping UK Free Shipping over £249

Buy 5 or More Units - Unlock Priority Discounts!
Buy 20 or More Units - Get Exclusive Volume Discounts!


Also Support: Google & Apple Pay

Are you a reseller or placing a large order?
We're happy to offer Special Pricing tailored to your needs.
Click "Request Quote" or email us at [email protected] to get your best price today!

Add to Wishlist

Compare

Product Code: MNHO-281

MPN #: ARK-1125H-S0A1

Advantech ARK-1125H, Intel® Processor N-series N200, DDR5 4800 MHz Embedded PC



The Industrial Embedded Computer is a compact and rugged fanless system designed for industrial automation, edge computing, and IoT applications. Powered by the Intel® Processor N-series N200, it delivers reliable performance with low power consumption while supporting dual 2.5GbE networking, multiple I/O interfaces, and flexible expansion options. With features such as DDR5 memory support, NVMe storage, RS-232/422/485 serial communication, CANBus, GPIO, TPM security, and wide temperature operation, it is suitable for demanding industrial environments including control systems, gateways, smart manufacturing, and edge deployments.Manufactured in China.



Features



  • Intel® Processor N-series N200 QC SoC
  • DDR5-4800 SO-DIMM memory support up 16G
  • Dual HDMI independent display support 4K resolution
  • M.2 E Key and B Key for storage and wireless module installation
  • TPM on board for system security
  • -30 ~ 60 °C extended operating temperature
  • 12V lockable DC jack power input
  • Advantech DeviceOn support
  • RED certified with selected wireless module





Specifications:
Processor System
CPU Intel® Processor N-series N200
Frequency 1.0GHz
Core Number 4
BIOS AMI EFI 256 Mbit
Memory
Technology DDR5 4800 MHz
Max Capacity 16GB
Socket 1x 262-pin SO-DIMM
Graphic
Chipset Intel® UHD Graphics
HDMI 4096 x 2160@60Hz
Dual Display HDMI + HDMI
Ethernet
LAN1 Intel i226-LM, 2.5GbE, support Wake On LAN
LAN2 Intel i226-LM, 2.5GbE, support Wake On LAN
Audio Interface
Audio Realtek ALC888S, High Definition Audio, Mic-in and Line-out
I/O Interface
Serial Ports 2x RS232/422/485 (default RS-232) with auto flow control
USB Ports 2x USB3.2, 2x USB2.0
GPIO 8-bit Programmable DIO
CANBus 2x
Expansion
M.2 2x, 1x M.2 2230 E key (PCIe x1) and 1x M.2 2280 B key with nano SIM holder (PCIe x1)
TPM SLB9672XU2.0 FW15.22
Storage
NVMe 2x, 1x M.2 2230 E key (PCIe x1) and 1x M.2 2280 B key (PCIe x1)
Software Support
Microsoft Windows Windows 10 Enterprise
Linux Ubuntu
Power Requirement
Power Type AT/ATX
Power Input Voltage 12VDC
Minimum Power Input 12V, 5A
Power Adapter AC to DC, DC12 V/5 A, 60 W with lockable DC Jack
Power Consumption Typical (OS idle mode): 10.54 W, Max (Full loading): 29.18 W
Mechanical
Construction Aluminum housing
Mounting DIN-Rail/Wall/VESA Mounting Kits
Dimensions (W x H x D) 133 x 46.4 x 94.2mm (5.24" x 1.83" x 3.71") without mounting kits
Weight 0.7 kgs
Environment
Operating Temperature With extended temperature peripherals: -30 ~ 60 °C (-22 ~ 140 °F) with 0.7m/s air flow
Storage Temperature -40 ~ 85 °C (-40 ~ 185°F)
Relative Humidity 95% @ 40 °C (non-condensing)
Certification
EMC CE/FCC Class B, CCC, BSMI, UKCA, RED
Safety CB, UL, CCC, BSMI, UKCA



Downloads
Datasheet
