Power outages can shut down your servers in seconds, costing you data loss and downtime. The APC Smart UPS On Line 10kVA 10kW Rack Tower 230V gives you clean, uninterrupted power for critical equipment. It is built for data centers, server rooms and any place where a single loss of electricity can hurt your business. With this UPS you keep your machines running and protect them from voltage spikes.
APC Smart UPS On Line 10kVA 10kW Rack Tower 230V
Unexpected power loss or unstable voltage can bring your operations to a halt. That matters because every minute of downtime can mean lost revenue, angry customers, and damaged reputation. This UPS solves the problem with double-conversion online technology that delivers a pure sine-wave output and isolates your equipment from input fluctuations. It also includes a network management card so you can monitor status, receive alerts, and shut down servers gracefully before the battery runs out. The result is reliable uptime and peace of mind for any critical IT environment.
Usages of APC
The APC Smart UPS fits in standard 19-inch racks or can stand as a tower in a small office. Use it to protect server clusters, storage arrays, and networking gear in a data center. It works well for telecom equipment at remote sites where power quality is poor. Industrial control panels and medical imaging devices also benefit from its clean power. Anywhere you need continuous operation and protection from surges, this UPS is a solid choice.
Benefits
- Keeps servers and network gear running during outages.
- Protects sensitive hardware from surges and voltage spikes.
- Reduces energy cost with ECO mode that saves power when load is low.
- Allows remote monitoring and control through the built-in network card.
- Simple battery replacement with hot-swap design.
Key Features
- 10 kVA / 10 kW capacity.
- Double-conversion (online) topology.
- Pure sine-wave output with 2 % THD.
- 600 J surge energy rating.
- LCD display with LED status indicators.
- Embedded Network Management Card.
- PowerChute Network Shutdown software.
- Hot-swap, sealed-lead-acid battery.
- Auto-restart after power return.
- 55 dB low-noise operation.
- Multiple IEC C13 and C19 outlets.
- Ethernet, USB, and serial communication ports.
Specifications
| Features |
| Auto-restart |
Yes |
| Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm |
| Audible alarm(s) |
Yes |
| Noise level |
55 dB |
| Output voltage Total Harmonic Distortion (THD) |
2% |
| ECO mode |
Yes |
| Crest factor |
3:1 |
| Surge energy rating |
600 J |
| Output frequency |
50/60 Hz |
| Output operation voltage (max) |
240 V |
| Output operation voltage (min) |
220 V |
| Input frequency |
40/70 Hz |
| Input operation voltage (max) |
285 V |
| Input operation voltage (min) |
100 V |
| Waveform |
Sine |
| Output power |
10000 W |
| Output power capacity |
10 kVA |
| UPS topology |
Double-conversion (Online) |
| Ports & interfaces |
| Emergency Power Off (EPO) connector |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Serial interface |
Yes |
| USB port |
Yes |
| AC outlets quantity |
3 AC outlet(s) |
| Power plug |
Hardwire |
| AC outlet types |
C13 coupler, C19 coupler |
| Battery |
| Cold start |
Yes |
| Automatic battery test |
Yes |
| Hot-swap battery |
Yes |
| Battery recharge time |
4 h |
| Battery life (max) |
5 year(s) |
| Battery voltage |
96 V |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Design |
| International Protection (IP) code |
IP20 |
| LED indicators |
Yes |
| Display type |
LCD |
| Form factor |
Rackmount/Tower |
| Operational conditions |
| Non-operating altitude |
0 - 15240 m |
| Operating altitude |
0 - 2011.68 m |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
| Weight |
81.1 kg |
| Height |
217 mm |
| Depth |
620 mm |
| Width |
440 mm |
| Packaging data |
| Package weight |
83.1 kg |
| Package height |
414 mm |
| Package depth |
790 mm |
| Package width |
590 mm |
| Other features |
| Operating temperature (T-T) |
0 - 40 °C |
