Power outages and dirty electricity can shut down servers, damage data and cost you time. When a business loses power, critical applications stop, users get angry and revenue drops. The APC Smart-UPS SRT8KRMXLI gives you clean, uninterrupted power so your equipment stays on and your data stays safe. It does this with double-conversion technology, automatic battery backup and remote management tools.
APC Smart-UPS SRT8KRMXLI 8kVA Online Rackmount UPS, 6x C13, 4x C19, NMC with APC
Stay online even when the grid fails. This 8 kVA rack-mount UPS supplies pure sine-wave power to servers, storage arrays and network switches. It solves the common problem of sudden shutdowns that cause data loss and hardware wear. With an integrated network card, APC lets you monitor the unit from any browser and shut down computers safely before the battery runs out.
Usages
The UPS fits in a standard 6U rack and powers data-center servers that need continuous uptime. It works well for small-to-medium business networks, remote office routers and voice-over-IP equipment. You can also use it in a lab environment to protect test rigs or in a broadcast studio where audio-visual gear must not miss a beat.
Benefits
- Zero transfer time keeps applications running without interruption.
- Remote monitoring reduces on-site visits and saves labor.
- Hot-swap batteries let you replace power cells without shutting down.
- Built-in surge protection shields equipment from lightning spikes.
- Scalable runtime lets you add external battery packs for longer outages.
Key Features
- Double-conversion (online) topology for clean power.
- 6 C13 and 4 C19 outlets for diverse device connections.
- Integrated Network Management Card with SNMP and web UI.
- PowerChute Network Shutdown software for graceful server power-off.
- Hot-swap internal battery cartridges for easy maintenance.
- 6U rackmount design with tiltable LCD and 4-post rail kit.
- 94.8 % efficiency reduces energy waste.
- 55 dB noise level suitable for office environments.
- Auto-restart and audible alarms for quick recovery.
- Compliance with CE, EN/IEC, VDE and RoHS standards.
Specifications
| Features |
| Auto-restart |
Yes |
| Audible alarm(s) |
Yes |
| Surge protection |
Yes |
| Noise level |
55 dB |
| Output voltage Total Harmonic Distortion (THD) |
3% |
| Emergency Power Off (EPO) |
Yes |
| Crest factor |
3:1 |
| Efficiency |
94.8% |
| Number of output phases |
1 |
| Surge energy rating |
480 J |
| Output frequency regulation |
50/60 Hz |
| Output operation voltage (max) |
240 V |
| Output operation voltage (min) |
220 V |
| Input frequency |
40 - 70 Hz |
| Input operation voltage (max) |
476 V |
| Input operation voltage (min) |
100 V |
| Waveform |
Sine |
| Output power |
8000 W |
| Output power capacity |
8 kVA |
| UPS topology |
Double-conversion (Online) |
| Ports & interfaces |
| SmartSlot |
Yes |
| Serial interface type |
RJ-45 |
| Serial interface |
Yes |
| USB port |
Yes |
| Number of output IEC jumpers |
3 |
| AC outlets quantity |
10 AC outlet(s) |
| Power plug |
Hardwire |
| AC outlet types |
C13 coupler, C19 coupler |
| Battery |
| Battery capacity |
1728 VAh |
| Cold start |
Yes |
| Automatic battery test |
Yes |
| Hot-swap battery |
Yes |
| Battery recharge time |
1.5 h |
| Battery life (max) |
5 year(s) |
| Typical backup time at half load |
14.5 min |
| Typical backup time at full load |
5.2 min |
| Battery capacity |
1728 VAh |
| Battery capacity |
1728 VAh |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Design |
| LED indicators |
Status |
| Display type |
LCD |
| Rack capacity |
6U |
| Product colour |
Black |
| Form factor |
Rackmount/Tower |
| Operational conditions |
| Non-operating altitude |
0 - 15000 m |
| Operating altitude |
0 - 3000 m |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Certificates |
| Certification |
REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE |
| Compliance certificates |
RoHS |
| Packaging content |
| Quick installation guide |
Yes |
| Cables included |
USB cable |
| Rack mount kit |
Yes |
| Weight & dimensions |
| Weight |
111.8 kg |
| Height |
263 mm |
| Depth |
432 mm |
| Width |
715 mm |
| Packaging data |
| Package weight |
130 kg |
| Package height |
461 mm |
| Package depth |
1000 mm |
| Package width |
600 mm |
| Software CD |
Yes |
| Warranty card |
Yes |
| Temperature sensor |
Yes |
| Bracket |
Yes |
| Other features |
| Packaging content |
Web/SNMP Management Card |
| Operating temperature (T-T) |
0 - 40 °C |
