| Model Name |
NUQ2000M/NUQ3000M |
| Product Type |
5G NR ODU |
| Chipset and System |
|
| Modem Chip |
NUQ3000M: Qualcomm® SDX65 |
| Modem Chip |
NUQ2000M: Qualcomm® SDX62 (EMEA) |
| mmW (PC3) |
QTM545 |
| Features |
|
| Features |
mmWave (26 ~ 28GHz, 39GHz) and Sub-6 5G NR
NSA & SA dual-mode compatibility
Qualcomm SDX6x chipset
Gigabit-speed access with 5Gbps Ethernet
PoE PD support
Nano SIM (4FF) & eSIM option
IP-rated waterproof enclosure
NSA & SA dual-mode compatibility
|
| Interfaces |
|
| Ethernet |
5Gbps |
| Power |
PoE PD with PoE injector (30W) |
| Indicators |
Signal Bar (blue/green dual color) |
| SIM |
nano SIM / [optional] eSIM |
| BLE |
BLE 4.0 for Self-installation with Mobile App |
| Band |
|
| Band |
3GPP Release 16 |
| Band |
Sub-6 support NR CA, F+T, F+F, T+T |
| Band |
mmW support NSA mode-NUQ3000M |
| Band |
mmW support NSA mode as max. 4CC DL-NUQ2000M |
| Band |
FR1 + FR2 Dual Connectivity |
| Band |
LTE DL Cat. 20 |
| Band |
LTE & 5G NR EN_DC |
| Band |
NUQ2000M (EMEA) |
| Band |
LTE Band: B1,B3,B5,B7,B8,B18,B19,B20,B26,B28,B32,B38,B39,B40,B41,B42,B43,B46 |
| Band |
5G Band: n1,n3,n5,n7,n8,n20,n28,n38,n40,n41,n77,n78,n257,258 |
| Band |
NUQ3000M |
| Band |
LTE Band: B1,B2,B3,B4,B5,B7,B8,B12,B13,B14,B17,B18,B19,B20,B25,B26,B28,
B29,B30,B32,B34,B38,B39,B40,B41,B42,B43,B46,B48,B66,B71
|
| Band |
5G Band: n1,n2,n3,n5,n7,n8,n12,n20,n25,n28,n38,n40,n41,n48,n66,
n71,n77,n78,n79,n257,258,n260,n261
|
| Dimensions |
|
| Dimensions |
100 x 170 x 36.95 (WxHxD, mm) |
| Environmental |
|
| Sealing |
IP67 |
| Operating Temperature |
-40℃~ 55℃ |
