ASUS Chromebox 5a delivers performance and responsiveness to empower users with incredible productivity.
Performance for any workplace
ASUS Chromebox 5a delivers performance and responsiveness to empower users with incredible productivity
Specifications
| Processor |
| Maximum turbo power |
55 W |
| Processor base power |
15 W |
| Number of processors installed |
1 |
| Processor cache type |
Smart Cache |
| Processor cache |
12 MB |
| Efficient-core Max Turbo Frequency |
3.4 GHz |
| Performance-core Max Turbo Frequency |
4.6 GHz |
| Efficient cores |
8 |
| Performance cores |
2 |
| Processor boost frequency |
4.6 GHz |
| Processor threads |
12 |
| Processor cores |
10 |
| Processor model |
i5-1335U |
| Processor generation |
13th gen Intel® Core™ i5 |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Memory |
| Memory slots |
2x SO-DIMM |
| Internal memory type |
DDR4-SDRAM |
| Maximum internal memory |
32 GB |
| Internal memory |
8 GB |
| Storage |
| Compatible memory cards |
MicroSD (TransFlash) |
| Card reader integrated |
Yes |
| M.2 SSD size |
2280 (22 x 80 mm) |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
256 GB |
| Number of SSDs installed |
1 |
| Total SSDs capacity |
256 GB |
| Storage media |
SSD |
| Optical drive type |
No |
| Total storage capacity |
256 GB |
| Graphics |
| On-board graphics card model |
Intel Iris Xe Graphics |
| On-board graphics card family |
Intel Iris Xe Graphics |
| On-board GPU manufacturer |
Intel |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| Network |
| Bluetooth version |
5.3 |
| Bluetooth |
Yes |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN |
Yes |
| Ports & interfaces |
| DC-in jack |
Yes |
| Combo headphone/mic port |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPort version |
1.4 |
| DisplayPorts quantity |
1 |
| HDMI version |
2.1 |
| HDMI ports quantity |
2 |
| Thunderbolt 3 ports quantity |
0 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 2.0 ports quantity |
0 |
| Design |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Performance |
| Product type |
Mini PC |
| Software |
| Operating system installed |
ChromeOS |
| Power |
| Power supply |
90 W |
| Certificates |
| Certification |
BSMI/CB/CE/FCC/UL/Energy Star/C-Tick/WiFi/RF/VCCI |
| Weight & dimensions |
| Package weight |
1.8 kg |
| Package height |
69 mm |
| Package depth |
206 mm |
| Package width |
334 mm |
| Weight |
800 g |
| Height |
45.9 mm |
| Depth |
165.8 mm |
| Width |
166.5 mm |
| Display |
| Display included |
No |
| Other features |
| Maximum internal memory |
32 GB |
