Power outages and voltage spikes can shut down computers, servers, and networking gear. When that happens you lose work, risk data loss, and may damage expensive equipment. The Eaton 5P 1550VA Line-Interactive UPS 1100W Rackmount gives you clean, uninterrupted power so your devices stay on long enough to save work and keep operations running. It also protects against brownouts and short surges, giving you confidence that critical systems stay alive. Designed for rackmount environments, it fits neatly into standard 1U spaces and uses a lithium-ion battery that lasts longer than lead-acid.
Eaton 5P 1550VA Line-Interactive UPS 1100W Rackmount with Eaton
Never worry about a sudden blackout again. This unit is a line-interactive UPS that delivers up to 1100 W of clean power to servers, storage, and networking gear. It is built for data centers, small offices, and edge locations that need reliable backup in a compact rack-mount form. The UPS also includes a built-in LCD that shows load, battery, and runtime at a glance. Without Eatons technology you would be exposed to power loss that can halt productivity and cause costly downtime.
Usages
Use it in a server rack to protect a single server or a small group of network switches. It works well for point-of-sale terminals that run on C13 outlets. It can also back up a small home office workstation that needs six outlets and a stable sine-wave output. The optional network card lets you monitor the unit remotely, making it suitable for remote sites. It fits into standard 19-inch racks, so you can stack it with other networking gear without extra space.
Benefits
- Keeps your data safe by giving you time to shut down properly.
- Prevents hardware damage from voltage spikes and brownouts.
- Saves money by avoiding lost productivity during outages.
- Provides a quiet operation at only 45 dB, suitable for office spaces.
- Lets you monitor power status online with the optional network card.
Key Features
- 1550 VA / 1100 W capacity in a 1U rackmount size.
- Line-interactive topology with true sine-wave output.
- Lithium-ion battery for longer life and faster recharge.
- Six C13 outlets for easy connection of IT equipment.
- LCD display and button control for quick status checks.
- 97 % efficiency and power factor of 1 for low energy loss.
- Input range 150 V-294 V and output range 200 V-240 V.
- USB and RS-232 ports for local management.
- Optional network card for remote monitoring and alerts.
- Noise level of 45 dB and heat dissipation of 113 BTU/h.
Specifications
| Features |
| Noise level |
45 dB |
| Power factor |
1 |
| Efficiency |
97% |
| Heat dissipation |
113 BTU/h |
| Output frequency |
50/60 Hz |
| Output operation voltage (max) |
240 V |
| Output operation voltage (min) |
200 V |
| Input frequency |
47/70 Hz |
| Input operation voltage (max) |
294 V |
| Input operation voltage (min) |
150 V |
| Output power |
1100 W |
| Output power capacity |
1.55 kVA |
| UPS topology |
Line-Interactive |
| Ports & interfaces |
| RS-232 ports |
1 |
| USB port |
Yes |
| AC outlets quantity |
6 AC outlet(s) |
| Power plug |
C13 coupler |
| AC outlet types |
C13 coupler |
| Battery |
| Typical backup time at half load |
11 min |
| Typical backup time at full load |
4 min |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Design |
| Display type |
LCD |
| Control type |
Buttons |
| Rack capacity |
1U |
| Product colour |
Black, Silver |
| Form factor |
Rackmount |
| Operational conditions |
| Operating altitude |
1 - 3000 m |
| Operating relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Certificates |
| Compliance certificates |
CE, Federal Communications Commission (FCC), IECEx, RoHS, cUL, cULus |
| Packaging content |
| Quick installation guide |
Yes |
| Cables included |
Input power cable, RS-232, USB cable |
| Weight & dimensions |
| Weight |
15.8 kg |
| Height |
43 mm |
| Depth |
553 mm |
| Width |
436 mm |
| Other features |
| Operating temperature (T-T) |
0 - 40 °C |
