Power outages and voltage spikes can shut down computers, damage data and interrupt work. When a device loses power, you can lose unsaved files, stop a project, or even damage hardware. The Eaton 5P1550IRG2BS Line-Interactive UPS 1350W Sine 150-294V gives you clean, uninterrupted power so your equipment stays on and your data stays safe. It protects against blackouts, brownouts and surges, keeping you productive.
Eaton 5P1550IRG2BS Line-Interactive UPS 1350W Sine 150-294V with Eaton
This is a line-interactive UPS that supplies 1350 W of pure sine wave power. It is built for small offices, workstations and network gear that cannot afford sudden loss of electricity. If you have a desktop, a router or a small server, you need a device that can keep them running for a short time while the grid recovers. Eatons reputation for reliability makes this UPS a trusted choice for protecting critical electronics.
Usages
Use the UPS in a home office to protect a personal computer and monitor. Place it in a small server room to keep a file server and networking switch online during brief outages. It works well for point-of-sale terminals that need constant power for transactions. It can also protect medical monitoring devices that require stable electricity. Anywhere you need a few minutes of backup power, this unit fits.
Benefits
- Provides up to 1350 W of clean sine wave power, preventing data loss.
- Automatic Voltage Regulation corrects minor voltage swings without using battery.
- Quiet operation at 35 dB keeps the workspace comfortable.
- Six C13 outlets let you connect multiple devices with one unit.
- LCD display shows battery status, load level and alerts at a glance.
Key Features
- Line-interactive topology for fast response to power changes.
- 98.2 % efficiency reduces energy waste and operating cost.
- Input voltage range 150-294 V covers most regional power standards.
- Output voltage 150-240 V with 50/60 Hz frequency for global compatibility.
- Supports up to six 6 V VRLA batteries for extended runtime.
- One RS-232 serial port and a USB Type-B for monitoring and control.
- 1U rack-mountable design fits standard server cabinets.
- Heat dissipation of 654 BTU/h keeps the unit cool under load.
- Certified to IEC/EN, UL, CSA and CE standards for safety.
- Weight of 19 kg and compact dimensions make installation easy.
Specifications
| Features |
| Noise level |
35 dB |
| Efficiency |
98.2% |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Heat dissipation |
654 BTU/h |
| Automatic Voltage Regulation (AVR) |
Yes |
| Output frequency |
50/60 Hz |
| Output operation voltage (max) |
240 V |
| Input frequency |
47/70 Hz |
| Input operation voltage (max) |
294 V |
| Input operation voltage (min) |
150 V |
| Waveform |
Sine |
| Output power |
1350 W |
| UPS topology |
Line-Interactive |
| Ports & interfaces |
| Serial ports quantity |
1 |
| Serial interface type |
RS-232 |
| Serial interface |
Yes |
| USB port type |
USB Type-B |
| USB port |
Yes |
| AC outlets quantity |
6 AC outlet(s) |
| Power plug |
C14 coupler |
| AC outlet types |
C13 coupler |
| Battery |
| Battery capacity |
9 Ah |
| Number of batteries supported |
6 |
| Battery voltage |
6 V |
| Battery capacity |
9 Ah |
| Battery capacity |
9 Ah |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Design |
| Display type |
LCD |
| Rack capacity |
1U |
| Product colour |
Black, Silver |
| Form factor |
Tower |
| Operational conditions |
| Operating altitude |
0 - 3000 m |
| Operating relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Certificates |
| Certification |
IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS |
| Packaging content |
| Quick installation guide |
Yes |
| Manual |
Yes |
| Weight & dimensions |
| Weight |
19 kg |
| Height |
43.2 mm |
| Depth |
555 mm |
| Width |
438 mm |
| Other features |
| Operating temperature (T-T) |
0 - 40 °C |
