Power cuts and voltage spikes can shut down computers, lose data and damage equipment. When a business loses power, work stops and money is lost. The Eaton 5PX2200IRT2UG2BS 2.2 kVA Line-Interactive UPS gives you clean, uninterrupted power so your devices stay on and your data stays safe. It protects against outages, brownouts and surges, letting you keep working while the grid recovers.
Eaton 5PX2200IRT2UG2BS 2.2 kVA Line-Interactive UPS, Rack/Tower, 2200 W with Eaton
Imagine a UPS that fits both a rack and a tower, delivers 2200 W, and talks to your network for remote monitoring. That is the Eaton 5PX2200IRT2UG2BS UPS. It is built for servers, networking gear and critical workstations that cannot afford a sudden power loss. If you have experienced a crash during a storm, you know why a reliable UPS is essential. Eatons line-interactive technology smooths voltage swings and gives you enough battery time to shut down safely or switch to backup power.
Usages
Use this UPS in a small server room to protect rack-mounted servers and storage arrays. Place it on a desk to keep a high-performance workstation running during a brief outage. It works well in a remote office where the power supply is unstable. The unit can also back up network switches, routers and VoIP phones, ensuring that communication stays online even when the main line drops.
Benefits
- Stops data loss by giving you time to save work before power fails.
- Reduces equipment wear caused by voltage spikes.
- Quiet operation (40 dB) keeps the office environment calm.
- Remote monitoring lets you check status from any computer.
- Fits both rack and tower installations, saving space.
Key Features
- 2200 W (2.2 kVA) output power.
- Line-interactive topology with Automatic Voltage Regulation.
- 10 AC outlets (C13 and C19 couplers) for flexible connections.
- LCD display shows load, battery, and voltage status.
- One RS-232 serial port and one USB-type B port for management.
- Supports up to six 12 V, 7 Ah sealed lead-acid batteries.
- Input voltage range 150-240 V, output range 200-240 V.
- Operating temperature 0-40 C and humidity up to 90 %.
- Complies with IEC/EN 62040 standards, UL, CSA and ENERGY STAR.
- Includes rack-mount kit, power cable, serial and USB cables.
Specifications
| Features |
| Power protection features |
Overdischarge |
| Noise level |
40 dB |
| Output power factor |
1 |
| Power factor |
1 |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Automatic Voltage Regulation (AVR) |
Yes |
| Output frequency |
50/60 Hz |
| Output operation voltage (max) |
240 V |
| Output operation voltage (min) |
200 V |
| Input frequency |
47/70 Hz |
| Input operation voltage (min) |
150 V |
| Waveform |
Sine |
| Output power |
2200 W |
| Output power capacity |
2.2 kVA |
| UPS topology |
Line-Interactive |
| Ports & interfaces |
| Serial ports quantity |
1 |
| Serial interface type |
RS-232 |
| Serial interface |
Yes |
| USB 2.0 ports quantity |
1 |
| USB port type |
USB Type-B |
| USB port |
Yes |
| AC outlets quantity |
10 AC outlet(s) |
| Power plug |
C20 coupler |
| AC outlet types |
C13 coupler, C19 coupler |
| Battery |
| Battery capacity |
7 Ah |
| Automatic battery test |
Yes |
| Number of batteries supported |
6 |
| Battery voltage |
12 V |
| Battery capacity |
7 Ah |
| Battery capacity |
7 Ah |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Design |
| Display type |
LCD |
| Cable length |
1.8 m |
| Product colour |
Black, Silver |
| Form factor |
Rackmount/Tower |
| Operational conditions |
| Operating altitude |
0 - 3000 m |
| Operating relative humidity (H-H) |
0 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Certificates |
| Certification |
IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA 22.2 cTUVus EAC Cm UKCA Ukr KCC |
| Compliance certificates |
CE, REACH, RoHS |
| Packaging content |
| Quick installation guide |
Yes |
| Cables included |
Input power cable, Serial, USB cable |
| Rack mount kit |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
| Sustainability certificates |
ENERGY STAR |
| Weight & dimensions |
| Weight |
28.6 kg |
| Height |
240 mm |
| Depth |
770 mm |
| Width |
588 mm |
| Other features |
| Operating temperature (T-T) |
0 - 40 °C |
