Imagine losing your server data in the middle of a critical transaction. The Eaton 93PX Online UPS 20 kVA Tower with C13 & C19 Outlets keeps your equipment running when the grid fails. It delivers clean, uninterrupted power to protect computers, networking gear, and medical devices. If you have ever faced a sudden outage that halted work, this UPS is the safety net you need.
Eaton 93PX Online UPS 20 kVA Tower with C13 & C19 Outlets
Power spikes, brownouts, and total blackouts can corrupt data and damage expensive hardware. The cost of downtime for a small office or a clinic can quickly rise into thousands of dollars. This UPS solves the problem by using double-conversion online technology that isolates your devices from any input irregularities. It supplies a steady 20 kVA output, giving you enough capacity to run servers, workstations, and critical medical equipment without interruption.
Benefits
- Zero interruption during power loss, so your work never stops.
- Clean sine-wave output protects sensitive electronics from damage.
- Ten C13/C19 outlets let you connect many devices from one unit.
- Modular design makes future upgrades simple and cost-effective.
- Built-in monitoring via RS-232 helps you track performance and schedule maintenance.
Usages
The Eaton 93PX fits perfectly in a server room that needs reliable backup for racks or towers. Small businesses can place it on a desk to protect point-of-sale systems and office computers. Clinics use it to keep imaging equipment and patient monitors running during outages. It also works well in industrial control panels where continuous power is required for safety and compliance.
Key Features
- 20 kVA (20 000 W) output power.
- Double-conversion (online) topology for pure output.
- 10 AC outlets with C13 and C19 couplers.
- 1 RS-232 communication port for remote monitoring.
- 3U rack or tower mounting flexibility.
- Fixed input and output connections for easy wiring.
- Compliance with IEC/EN 62040 standards and CE, RoHS certifications.
- Black, compact tower design (129 mm high, 438 mm wide, 592 mm deep).
- Weight of 12.8 kg for stable placement.
- Quick installation guide and full user manual included.
Specifications
| Features |
| Auto shut-off |
No |
| Output operation voltage (min) |
250 V |
| Input operation voltage (min) |
250 V |
| Output power |
20000 W |
| Output power capacity |
20 kVA |
| UPS topology |
Double-conversion (Online) |
| Ports & interfaces |
| RS-232 ports |
1 |
| AC outlets quantity |
10 AC outlet(s) |
| AC outlet types |
C13 coupler, C19 coupler |
| Design |
| Modular |
Yes |
| Rack capacity |
3U |
| Product colour |
Black |
| Form factor |
Tower |
| Certificates |
| Certification |
IEC/EN 62040-2 IEC/EN 62040-1 EN 62040-3 |
| Compliance certificates |
CE, RoHS |
| Packaging content |
| Quick installation guide |
Yes |
| Manual |
Yes |
| Weight & dimensions |
| Weight |
12.8 kg |
| Height |
129 mm |
| Depth |
592 mm |
| Width |
438 mm |
| Other features |
| Output connection type |
Fixed |
| Input connection type |
Fixed |
